Name: Lower timing case
Rating: 4.0 (1 reviews)

View the exploded parts diagram to find the part you are looking for

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

TO ORDER

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	11148620773	Timing case cover	$351.46	To Order

Photo	Part No	Description	Price (each)	Stock
	11 14 7563860	Gasket f timing case	$20.65	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	11147647380	Shaft seal	$52.34	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	11 14 7574332	Chain guide	$51.98	To Order

Photo	Part No	Description	Price (each)	Stock
	07 11 9905400	Hex Bolt with washer	$1.11	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	07119908640	Hexalobular socket screw	$2.44	To Order

Photo	Part No	Description	Price (each)	Stock
	07119907836	Hexalobular socket screw	$3.11	To Order

Photo	Part No	Description	Price (each)	Stock
	07129909333	Torx screw, self-locking	$2.00	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	11 12 1726238	Dowel	$0.97	To Order

Photo	Part No	Description	Price (each)	Stock
	11 12 1726245	Dowel	$1.08	To Order

Photo	Part No	Description	Price (each)	Stock
	11 53 1710048	O-ring	$2.41	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	64558620575	Bracket, A/C compressor	$90.86	To Order

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Key
-	83 19 0404517	Liquid sealant, Loctite 5970	83 19 0404517 Liquid sealant, Loctite 5970 50ML	$24.54	1	TO
1	11148620773	Timing case cover	11148620773 Timing case cover	$351.46	1	TO
2	11 14 7563860	Gasket f timing case IN STOCK	11 14 7563860 Gasket f timing case IN STOCK	$20.65	1	IN
3	11147647380	Shaft seal IN STOCK	11147647380 Shaft seal 45X75X8/11,9 IN STOCK	$52.34	1	IN
4	11 14 7574332	Chain guide	11 14 7574332 Chain guide	$51.98	1	TO
5	07 11 9905400	Hex Bolt with washer IN STOCK	07 11 9905400 Hex Bolt with washer M6X25-ZNNIV SI IN STOCK	$1.11	1	IN
6	07119908640	Hexalobular socket screw	07119908640 Hexalobular socket screw M8X70-8.8-ZNS3	$2.44	6	TO
7	07119907836	Hexalobular socket screw	07119907836 Hexalobular socket screw BM8X40-8.8-ZNNI	$3.11	5	TO
8	07129909333	Torx screw, self-locking IN STOCK	07129909333 Torx screw, self-locking M8X25-U1-8.8 IN STOCK	$2.00	1	IN
9	11 12 1726238	Dowel	11 12 1726238 Dowel D=10,5MM	$0.97	2	TO
10	11 12 1726245	Dowel	11 12 1726245 Dowel D=11,1MM	$1.08	1	TO
11	11 53 1710048	O-ring IN STOCK	11 53 1710048 O-ring 34,2X4,0MM IN STOCK	$2.41	1	IN
12	64558620575	Bracket, A/C compressor	64558620575 Bracket, A/C compressor	$90.86	1	TO

Lower Timing Case

Rolls Royce Phantom Extended RR12(2017-2023)
