Seat Rear Electrical System And Drives

Rolls Royce Phantom Extended RR12(2017-2023)

Find Your Part

Rolls Royce Phantom Extended RR12(2017-2023) - Seat rear electrical system and drives

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
52107454063 Drive, longitudinal seat adjustment left $408.14 To Order
52107454064 Drive, longitudinal seat adjustment rght $408.14 To Order
Photo Part No Description Price (each) Stock
52107454065 Drive, backrest angle adjustment, left $340.11 To Order
52107454066 Drive, backrest angle adjustment, right $340.11 To Order
Photo Part No Description Price (each) Stock
52107454062 Drive, vertical headrest adjustment $306.09 To Order
Photo Part No Description Price (each) Stock
52107454067 Actuator f upper backrest adjustment $340.11 To Order
Photo Part No Description Price (each) Stock
52107314213 Gearing, backrest top adjustment $170.05 To Order
Photo Part No Description Price (each) Stock
52107454068 Set of flexible shafts $327.44 To Order
Photo Part No Description Price (each) Stock
52207368576 Fan for A/C box $180.86 To Order
Photo Part No Description Price (each) Stock
07149200941 Oval-head screw with washer $1.36 To Order
Photo Part No Description Price (each) Stock
63131378066 Expanding nut $0.95 To Order
Photo Part No Description Price (each) Stock
52107454072 set of fittings for seat drive $197.87 To Order
Seat rear electrical system and drives of Rolls Royce Rolls Royce Phantom Extended RR12(2017-2023) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 52107454063
Drive, longitudinal seat adjustment left 		$408.14 1
TO
1 52107454064
Drive, longitudinal seat adjustment rght 		$408.14 1
TO
2 52107454065
Drive, backrest angle adjustment, left 		$340.11 1
TO
2 52107454066
Drive, backrest angle adjustment, right 		$340.11 1
TO
3 52107454062
Drive, vertical headrest adjustment 		$306.09 2
TO
4 52107454067
Actuator f upper backrest adjustment 		$340.11 2
TO
5 52107314213
Gearing, backrest top adjustment 		$170.05 2
TO
6 52107454068
Set of flexible shafts 		$327.44 2
TO
7 52207368576
Fan for A/C box 		$180.86 2
TO
8 07149200941
Oval-head screw with washer
DELTA PT4X12 		$1.36 4
TO
9 63131378066
Expanding nut 		$0.95 4
TO
10 52107454072
set of fittings for seat drive 		$197.87 2
TO
