Rear Electric Axle - Powertrain

Maserati Grecale Folgore Automatic 4WD BEV 400 kW

Find Your Part

Maserati Grecale Folgore Automatic 4WD BEV 400 kW - REAR ELECTRIC AXLE - POWERTRAIN

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
670304428 REAR ELECTRIC TRACTION MODULE $4,470.49 To Order
Photo Part No Description Price (each) Stock
670178955 LH LOWER BRACKET $220.09 To Order
Photo Part No Description Price (each) Stock
670178956 RH LOWER BRACKET $237.61 To Order
Photo Part No Description Price (each) Stock
670178953 LH UPPER BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
670178954 RH UPPER BRACKET $43.66 To Order
Photo Part No Description Price (each) Stock
670178314 ENGINE GROUND CABLE $25.64 To Order
Photo Part No Description Price (each) Stock
670179006 SCREW $3.43 To Order
Photo Part No Description Price (each) Stock
670179008 SCREW $3.43 To Order
Photo Part No Description Price (each) Stock
670215585 SCREW $10.60 To Order
Photo Part No Description Price (each) Stock
670307980 VENT VALVE $177.40 To Order
Photo Part No Description Price (each) Stock
670307991 COMPLETE OIL CAP Enquire To Order
Photo Part No Description Price (each) Stock
670307992 WASHER $19.42 To Order
Photo Part No Description Price (each) Stock
670307990 COOLANT OUTLET FLANGE Enquire To Order
Photo Part No Description Price (each) Stock
670307994 UPPER COVER Enquire To Order
Photo Part No Description Price (each) Stock
670307998 COVER Enquire To Order
Photo Part No Description Price (each) Stock
670307999 SCREW $33.17 To Order
Photo Part No Description Price (each) Stock
670307997 GASKET $68.98 To Order
Photo Part No Description Price (each) Stock
670307986 SCREW $18.56 To Order
Photo Part No Description Price (each) Stock
670307993 SCREW $31.24 To Order
Photo Part No Description Price (each) Stock
670307995 GASKET $44.75 To Order
REAR ELECTRIC AXLE - POWERTRAIN of Maserati Maserati Grecale Folgore Automatic 4WD BEV 400 kW Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 670304428
REAR ELECTRIC TRACTION MODULE
EU AU US UK JP ME JRH IN KO; 		$4,470.49 1
TO
2 670178955
LH LOWER BRACKET 		$220.09 1
TO
3 670178956
RH LOWER BRACKET 		$237.61 1
TO
4 670178953
LH UPPER BRACKET 		- 1
PE
 Enquire
5 670178954
RH UPPER BRACKET 		$43.66 1
TO
6 670178314
ENGINE GROUND CABLE 		$25.64 1
TO
7 670179006
SCREW 		$3.43 8
TO
8 670179008
SCREW 		$3.43 3
TO
9 670215585
SCREW 		$10.60 4
TO
14 670307980
VENT VALVE 		$177.40 2
TO
15 670307991
COMPLETE OIL CAP 		- 1
PE
 Enquire
16 670307992
WASHER 		$19.42 1
TO
17 670307990
COOLANT OUTLET FLANGE 		- 1
PE
 Enquire
18 670307994
UPPER COVER 		- 1
PE
 Enquire
19 670307998
COVER 		- 1
PE
 Enquire
20 670307999
SCREW 		$33.17 11
TO
21 670307997
GASKET 		$68.98 1
TO
22 670307986
SCREW 		$18.56 1
TO
23 670307993
SCREW 		$31.24 8
TO
24 670307995
GASKET 		$44.75 1
TO
