Name: 1 SET FUEL PIPES
Rating: 4.5 (1 reviews)

Diagram
INFO

1 SET FUEL PIPES of Lamborghini Lamborghini Urus (2019-2022)

Lamborghini Urus (2019-2022) - 1 SET FUEL PIPES

View the exploded parts diagram to find the part you are looking for

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

TO ORDER

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4M0201544BD	1 SET FUEL PIPES	$246.30	To Order
	4M0201544BK	1 SET FUEL PIPES	$366.46	To Order
	4M0201544BK	1 SET FUEL PIPES	$366.46	To Order

Photo	Part No	Description	Price (each)	Stock
	4D0201449D	SECURING CLIP	$2.89	To Order
	4M0201449F	SECURING CLIP	$6.26	To Order

Photo	Part No	Description	Price (each)	Stock
	4D0201245G	PROTECTIVE PROFILE	$8.01	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0201190C	SECURING CLIP	$2.77	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0201196F	SEAL	$5.13	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT008695	SHOULDERED BOLT	$1.97	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0201192K	COVER	$31.41	To Order

Photo	Part No	Description	Price (each)	Stock
	N10737001	HEXAGON NUT, SELF-LOCKING	$2.11	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0201994AR	BREATHER LINE	$74.49	To Order

Photo	Part No	Description	Price (each)	Stock
	N90926401	SPRING BAND CLAMP	$3.69	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4B0422379	SPRING BAND CLAMP	$2.77	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10843101	SECURING CLIP	$2.89	To Order
	N10857701	SECURING CLIP	$3.76	To Order

Photo	Part No	Description	Price (each)	Stock
	4F0611853A	SPACER RING	$5.39	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0201215Q	FUEL HOSE	$114.15	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0201196G	SEAL	$31.28	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0201196N	SEAL	$16.36	To Order

Diagram Tap to enlarge

	#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Key
	1	4M0201544BD	1 SET FUEL PIPES	4M0201544BD 1 SET FUEL PIPES W/O AUXILIARY HEATER	$246.30	1	TO
	4M0201544BK		1 SET FUEL PIPES	from $366.46
1 1 SET FUEL PIPES $366.46 1 TO 1 1 SET FUEL PIPES $366.46 1 TO
	3	4D0201449D	SECURING CLIP	4D0201449D SECURING CLIP W/O AUXILIARY HEATER	$2.89	1	TO
	3	4M0201449F	SECURING CLIP	4M0201449F SECURING CLIP WITH AUXILIARY HEATER - NOT FOR SOUTH KOREA	$6.26	1	TO
	4	4D0201245G	PROTECTIVE PROFILE	4D0201245G PROTECTIVE PROFILE 12MM	$8.01	1	TO
	5	4M0201190C	SECURING CLIP	4M0201190C SECURING CLIP	$2.77	8	TO
	6	4M0201196F	SEAL	4M0201196F SEAL	$5.13	1	TO
	7	WHT008695	SHOULDERED BOLT	WHT008695 SHOULDERED BOLT M6X12 -5	$1.97	1	TO
	8	4M0201192K	COVER	4M0201192K COVER	$31.41	1	TO
	9	N10737001	HEXAGON NUT, SELF-LOCKING	N10737001 HEXAGON NUT, SELF-LOCKING M6	$2.11	4	TO
	10	4M0201994AR	BREATHER LINE	4M0201994AR BREATHER LINE EU6 BG	$74.49	1	TO
	11	N90926401	SPRING BAND CLAMP IN STOCK	N90926401 SPRING BAND CLAMP 19X12 IN STOCK	$3.69	1	IN
	12	4B0422379	SPRING BAND CLAMP IN STOCK	4B0422379 SPRING BAND CLAMP 16X12 IN STOCK	$2.77	2	IN
	14	N10843101	SECURING CLIP	N10843101 SECURING CLIP A14-17XC12-6 -5	$2.89	1	TO
	14	N10857701	SECURING CLIP	N10857701 SECURING CLIP ONLY FOR OPF - CHINA-A14-17XC12-6.5	$3.76	1	TO
	15	4F0611853A	SPACER RING	4F0611853A SPACER RING 10 -5X6X50	$5.39	2	TO
	16	4M0201215Q	FUEL HOSE	4M0201215Q FUEL HOSE EU6 PLUS-FEED	$114.15	1	TO
	17	4M0201196G	SEAL	4M0201196G SEAL	$31.28	1	TO
	18	4M0201196N	SEAL	4M0201196N SEAL 3 POINT	$16.36	2	TO

1 Set Fuel Pipes

Lamborghini Urus (2019-2022)

Lamborghini Urus (2019-2022) - 1 SET FUEL PIPES
