Brake Servo System

Maserati Levante Modena S Automatic 3.0 BT V6 4WD 430HP

Find Your Part

Maserati Levante Modena S Automatic 3.0 BT V6 4WD 430HP - BRAKE SERVO SYSTEM

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
670036711 POWER BRAKES ASSY $592.42 To Order
Photo Part No Description Price (each) Stock
673005988 SERVO BRAKE $662.49 To Order
Photo Part No Description Price (each) Stock
673005990 BRAKE PUMP $451.16 To Order
Photo Part No Description Price (each) Stock
670102492 VACUUM PIPE ASSEMBLY $102.07 To Order
Photo Part No Description Price (each) Stock
675000262 PRESSURE TRANSMITTER $78.57 To Order
Photo Part No Description Price (each) Stock
673002019 GASKET $44.51 To Order
Photo Part No Description Price (each) Stock
675000013 CLIP $1.09 To Order
Photo Part No Description Price (each) Stock
673009227 GASKET $2.60 To Order
Photo Part No Description Price (each) Stock
673002073 GASKET $13.51 To Order
Photo Part No Description Price (each) Stock
673007334 TANK KIT $208.46 To Order
Photo Part No Description Price (each) Stock
673009226 SPACER $47.77 To Order
Photo Part No Description Price (each) Stock
670153081 SHIELD FOR WATER $7.62 To Order
Photo Part No Description Price (each) Stock
675001939 NUT $2.28 To Order
Photo Part No Description Price (each) Stock
673017049 SCREW $11.59 To Order
BRAKE SERVO SYSTEM of Maserati Maserati Levante Modena S Automatic 3.0 BT V6 4WD 430HP Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 670036711
POWER BRAKES ASSY
IF STOCK =0 ORDER THE INDIVIDUAL SUB-COMPONENTS; 		$592.42 1
TO
2 673005988
SERVO BRAKE 		$662.49 1
TO
3 673005990
BRAKE PUMP 		$451.16 1
TO
4 670102492
VACUUM PIPE ASSEMBLY
Bespoke Assembly Number 6035538 - 99999999; 		$102.07 1
TO
5 675000262
PRESSURE TRANSMITTER 		$78.57 1
TO
6 673002019
GASKET 		$44.51 1
TO
7 675000013
CLIP 		$1.09 1
TO
8 673009227
GASKET 		$2.60 1
TO
9 673002073
GASKET 		$13.51 1
TO
10 673007334
TANK KIT 		$208.46 1
TO
11 673009226
SPACER 		$47.77 1
TO
13 670153081
SHIELD FOR WATER 		$7.62 1
TO
14 675001939
NUT 		$2.28 4
TO
15 673017049
SCREW 		$11.59 1
TO
