Name: FRONT WHEELS TRANSMISSION
Rating: 5.0 (1 reviews)

FRONT WHEELS TRANSMISSION of Maserati Maserati Grecale Trofeo Automatic 3.0 BT V6 530HP

View All

Maserati Grecale Trofeo Automatic 3.0 BT V6 530HP - FRONT WHEELS TRANSMISSION (03223)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	675001937	FRONT DIFFERENTIAL	$2,372.21	To Order

Photo	Part No	Description	Price (each)	Stock
	46341888	FRONT DRIVE SHAFT	$762.96	To Order

Photo	Part No	Description	Price (each)	Stock
	670003772	PLATE	$4.08	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	670302678	SCREW	$2.47	To Order
	670302678	SCREW	$2.47	To Order

Photo	Part No	Description	Price (each)	Stock
	670154265	ALL WHEEL DRIVE TRANSFER CASE	$1,391.43	To Order

Photo	Part No	Description	Price (each)	Stock
	675001724	LH AXLE SHAFT ASSEMBLY	$414.21	To Order

Photo	Part No	Description	Price (each)	Stock
	675001722	RH AXLE SHAFT ASSEMBLY	$595.13	To Order

Photo	Part No	Description	Price (each)	Stock
	675001849	SCREW	$2.78	To Order

Photo	Part No	Description	Price (each)	Stock
	675001859	SCREW	$3.27	To Order

Photo	Part No	Description	Price (each)	Stock
	670175707	TRANSFER CASE CONTROL UNIT	$560.35	To Order

Photo	Part No	Description	Price (each)	Stock
	675001850	SCREW	$3.48	To Order

Photo	Part No	Description	Price (each)	Stock
	675000138	NUT	$10.15	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	675002077	VENT PIPE	$32.63	To Order

Photo	Part No	Description	Price (each)	Stock
	670051525	BUSHING	$29.67	To Order

Photo	Part No	Description	Price (each)	Stock
	675002078	SCREW	$6.50	To Order

Photo	Part No	Description	Price (each)	Stock
	675000719	GASKET	$3.15	To Order

Photo	Part No	Description	Price (each)	Stock
	675001861	BRACKET	$10.38	To Order

Photo	Part No	Description	Price (each)	Stock
	675001931	SCREW	$1.48	To Order

Photo	Part No	Description	Price (each)	Stock
	46347065	HEAT SHIELD	$15.13	To Order

Photo	Part No	Description	Price (each)	Stock
	675000102	SCREWM6X14	$2.93	To Order

Photo	Part No	Description	Price (each)	Stock
	670052920	BRACKET	$19.30	To Order

Photo	Part No	Description	Price (each)	Stock
	670051104	SCREW	$2.47	To Order

Photo	Part No	Description	Price (each)	Stock
	675001909	SCREW	$1.68	To Order

Photo	Part No	Description	Price (each)	Stock
	673015767	COMPLETE OIL CAP	$2.07	To Order

Photo	Part No	Description	Price (each)	Stock
	673015768	O.R. GASKET	$1.63	To Order

Photo	Part No	Description	Price (each)	Stock
	673015772	GASKET	$4.66	To Order

Photo	Part No	Description	Price (each)	Stock
	673015774	SCREW	$2.74	To Order

View All

Diagram Tap to enlarge

Front Wheels Transmission

Maserati Grecale Trofeo Automatic 3.0 BT V6 530HP

Illustration Number: 03223

Maserati Grecale Trofeo Automatic 3.0 BT V6 530HP - FRONT WHEELS TRANSMISSION (03223)

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	675001937	FRONT DIFFERENTIAL	675001937 FRONT DIFFERENTIAL	$2,372.21	1
2	46341888	FRONT DRIVE SHAFT	46341888 FRONT DRIVE SHAFT	$762.96	1
3	670003772	PLATE IN STOCK	670003772 PLATE IN STOCK	$4.08	3
4	670302678	SCREW	670302678 SCREW	$2.47	6
4	670302678	SCREW	670302678 SCREW Bespoke Assembly Number 0 - 2025847;	$2.47	6
5	670154265	ALL WHEEL DRIVE TRANSFER CASE	670154265 ALL WHEEL DRIVE TRANSFER CASE Not available with: CHINA 6B EMISSION;	$1,391.43	1
6	675001724	LH AXLE SHAFT ASSEMBLY	675001724 LH AXLE SHAFT ASSEMBLY	$414.21	1
7	675001722	RH AXLE SHAFT ASSEMBLY	675001722 RH AXLE SHAFT ASSEMBLY	$595.13	1
8	675001849	SCREW	675001849 SCREW	$2.78	5
9	675001859	SCREW	675001859 SCREW	$3.27	3
10	670175707	TRANSFER CASE CONTROL UNIT	670175707 TRANSFER CASE CONTROL UNIT Not available with: CHINA 6B EMISSION;	$560.35	1
11	675001850	SCREW	675001850 SCREW	$3.48	3
12	675000138	NUT IN STOCK	675000138 NUT IN STOCK	$10.15	2
13	675002077	VENT PIPE	675002077 VENT PIPE	$32.63	1
14	670051525	BUSHING	670051525 BUSHING	$29.67	1
15	675002078	SCREW	675002078 SCREW	$6.50	1
16	675000719	GASKET	675000719 GASKET	$3.15	1
17	675001861	BRACKET	675001861 BRACKET	$10.38	1
18	675001931	SCREW	675001931 SCREW	$1.48	1
19	46347065	HEAT SHIELD	46347065 HEAT SHIELD	$15.13	1
20	675000102	SCREWM6X14	675000102 SCREWM6X14	$2.93	4
21	670052920	BRACKET	670052920 BRACKET	$19.30	1
22	670051104	SCREW	670051104 SCREW	$2.47	1
23	675001909	SCREW	675001909 SCREW	$1.68	4
27	673015767	COMPLETE OIL CAP	673015767 COMPLETE OIL CAP	$2.07	2
28	673015768	O.R. GASKET	673015768 O.R. GASKET	$1.63	1
29	673015772	GASKET	673015772 GASKET	$4.66	1
30	673015774	SCREW	673015774 SCREW	$2.74	2
