Charging System

Maserati GranCabrio M189 FOLGORE AUTOMATIC 4WD BEV 560 kW

Find Your Part

Maserati GranCabrio M189 FOLGORE AUTOMATIC 4WD BEV 560 kW - CHARGING SYSTEM

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
670216739 PRESA DI RICARICA $2,100.03 To Order
Photo Part No Description Price (each) Stock
670309188 AC/DC BATTERY CHARGER $3,827.90 To Order
Photo Part No Description Price (each) Stock
670159283 high voltage charger wiring $238.17 To Order
Photo Part No Description Price (each) Stock
670213206 HV WIRING BRACKET $46.80 To Order
Photo Part No Description Price (each) Stock
670213153 BRACKET $35.35 To Order
Photo Part No Description Price (each) Stock
670213676 BRACKET $168.87 To Order
Photo Part No Description Price (each) Stock
670213678 rh lateral ball joint $50.81 To Order
Photo Part No Description Price (each) Stock
670213677 lh lateral ball joint $57.17 To Order
Photo Part No Description Price (each) Stock
670217937 BRACKET $9.88 To Order
Photo Part No Description Price (each) Stock
670217938 BRACKET $9.88 To Order
Photo Part No Description Price (each) Stock
675002299 SCREW $1.06 To Order
Photo Part No Description Price (each) Stock
670213674 BRACKET $39.57 To Order
Photo Part No Description Price (each) Stock
670300002 DC BOOSTER $5,316.54 To Order
Photo Part No Description Price (each) Stock
670159306 HVBS-DCBC HIGH VOLTAGE WIRING $981.44 To Order
Photo Part No Description Price (each) Stock
670051451 SCREW $3.43 To Order
Photo Part No Description Price (each) Stock
675002282 SCREW $0.88 To Order
Photo Part No Description Price (each) Stock
675002361 SCREW $3.55 To Order
Photo Part No Description Price (each) Stock
670159274 GROUND WIRE $87.74 To Order
Photo Part No Description Price (each) Stock
670159275 GROUND WIRE $36.79 To Order
CHARGING SYSTEM of Maserati Maserati GranCabrio M189 FOLGORE AUTOMATIC 4WD BEV 560 kW Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 670216739
PRESA DI RICARICA
Available with: PLUG TYPE2 CCS2, 50KW RECHARGE Not available with: PLUG TYPE1 CCS1, PLUG GBT; 		$2,100.03 1
TO
2 670309188
AC/DC BATTERY CHARGER
EU AU US UK JP ME JRH IN KO UK3 GB; 		$3,827.90 1
TO
3 670159283
high voltage charger wiring 		$238.17 1
TO
4 670213206
HV WIRING BRACKET 		$46.80 1
TO
5 670213153
BRACKET
EU AU US UK JP ME JRH IN KO UK3 GB; 		$35.35 1
TO
6 670213676
BRACKET 		$168.87 1
TO
7 670213678
rh lateral ball joint 		$50.81 1
TO
8 670213677
lh lateral ball joint 		$57.17 1
TO
9 670217937
BRACKET 		$9.88 1
TO
10 670217938
BRACKET 		$9.88 1
TO
11 675002299
SCREW
Available with: 50KW RECHARGE ; EU US UK UK3 GB; 		$1.06 5
TO
12 670213674
BRACKET
Available with: 50KW RECHARGE ; EU US UK UK3 GB; 		$39.57 1
TO
13 670300002
DC BOOSTER
Available with: 50KW RECHARGE ; EU US UK UK3 GB; 		$5,316.54 1
TO
14 670159306
HVBS-DCBC HIGH VOLTAGE WIRING
Available with: 50KW RECHARGE ; 		$981.44 1
TO
15 670051451
SCREW 		$3.43 4
TO
16 675002282
SCREW 		$0.88 4
TO
17 675002361
SCREW 		$3.55 4
TO
18 670159274
GROUND WIRE
Available with: 50KW RECHARGE ; 		$87.74 1
TO
19 670159275
GROUND WIRE 		$36.79 1
TO
