Braking Devices On Rear Wheels

Maserati GranCabrio M189 TROFEO AUTOMATIC 4WD 3.0 BT V6 550 HP

Find Your Part

Maserati GranCabrio M189 TROFEO AUTOMATIC 4WD 3.0 BT V6 550 HP - BRAKING DEVICES ON REAR WHEELS

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
670161622 REAR BRAKE DISC $519.25 To Order
Photo Part No Description Price (each) Stock
675000081 SCREW M10 $5.76 To Order
Photo Part No Description Price (each) Stock
670158692 LH REAR BRAKE DISC SHIELD $14.13 To Order
670158693 RH REAR BRAKE DISC SHIELD $14.13 To Order
Photo Part No Description Price (each) Stock
675001032 SCREW $1.42 To Order
Photo Part No Description Price (each) Stock
670294145 brake rear lh yellow $970.95 To Order
670294146 BRAKE REAR LH BLACK ANODIZED $752.62 To Order
670307752 LH REAR CALIPER ASSEMBLY Enquire To Order
...and 15 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
675001192 SCREW $5.46 To Order
Photo Part No Description Price (each) Stock
670158702 FLEXIBLE HOSE $11.29 To Order
Photo Part No Description Price (each) Stock
670162021 BRAKE CLAMP REAR LH $7.11 To Order
670162020 BRAKE CLAMP REAR RH $7.11 To Order
Photo Part No Description Price (each) Stock
675000432 SCREWM6X20 $2.54 To Order
Photo Part No Description Price (each) Stock
673014160 REAR BRAKE PADS $325.65 To Order
Photo Part No Description Price (each) Stock
673010932 SPRING AND PINS KIT $122.59 To Order
Photo Part No Description Price (each) Stock
673001646 BLEEDER SCREW AND PLUG $33.78 To Order
Photo Part No Description Price (each) Stock
673010936 LH BRACKET AND SCREW $51.13 To Order
673010935 RH BRACKET AND SCREW $51.13 To Order
BRAKING DEVICES ON REAR WHEELS of Maserati Maserati GranCabrio M189 TROFEO AUTOMATIC 4WD 3.0 BT V6 550 HP Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 670161622
REAR BRAKE DISC 		$519.25 2
TO
2 675000081
SCREW M10 		$5.76 2
TO
3 670158692
LH REAR BRAKE DISC SHIELD 		$14.13 1
TO
3 670158693
RH REAR BRAKE DISC SHIELD 		$14.13 1
TO
4 675001032
SCREW 		$1.42 6
TO
5 670294145
brake rear lh yellow
Available with: BRAKE CALIPERS PAINTED IN YELLOW Not available with: BRAKE CALIPERS IN BLUE, BRAKE CALIPERS ANODIZED IN RED, BRAKE CALIPERS IN DARK COPPER, BRAKE CALIPERS ANODIZED IN BLACK, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS; 		$970.95 1
TO
5 670294146
BRAKE REAR LH BLACK ANODIZED
Available with: BRAKE CALIPERS ANODIZED IN BLACK Not available with: BRAKE CALIPERS IN BLUE, BRAKE CALIPERS ANODIZED IN RED, BRAKE CALIPERS IN DARK COPPER, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS, BRAKE CALIPERS PAINTED IN YELLOW; 		$752.62 1
TO
5 670307752
LH REAR CALIPER ASSEMBLY
Available with: FUORISERIE - BRAKE CALIPERS PAINTED - GIALLO LIME Not available with: FUORISERIE - WHITE BRAKE CALIPERS, FUORISERIE - ORANGE BRAKE CALIPERS; 		- 1
PE
 Enquire
5 670307753
LH REAR CALIPER ASSEMBLY
Available with: FUORISERIE - WHITE BRAKE CALIPERS Not available with: FUORISERIE - BRAKE CALIPERS PAINTED - GIALLO LIME, FUORISERIE - ORANGE BRAKE CALIPERS; 		- 1
PE
 Enquire
5 670307754
LH REAR CALIPER ASSEMBLY
Available with: FUORISERIE - ORANGE BRAKE CALIPERS Not available with: FUORISERIE - BRAKE CALIPERS PAINTED - GIALLO LIME, FUORISERIE - WHITE BRAKE CALIPERS; 		- 1
PE
 Enquire
5 670294184
brake rear rh yellow
Available with: BRAKE CALIPERS PAINTED IN YELLOW Not available with: BRAKE CALIPERS IN BLUE, BRAKE CALIPERS ANODIZED IN RED, BRAKE CALIPERS IN DARK COPPER, BRAKE CALIPERS ANODIZED IN BLACK, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS; 		$970.95 1
TO
5 670294185
brake rear rh black anodized
Available with: BRAKE CALIPERS ANODIZED IN BLACK Not available with: BRAKE CALIPERS IN BLUE, BRAKE CALIPERS ANODIZED IN RED, BRAKE CALIPERS IN DARK COPPER, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS, BRAKE CALIPERS PAINTED IN YELLOW; 		$970.95 1
TO
5 670307749
RH REAR CALIPER ASSEMBLY
Available with: FUORISERIE - BRAKE CALIPERS PAINTED - GIALLO LIME Not available with: FUORISERIE - WHITE BRAKE CALIPERS, FUORISERIE - ORANGE BRAKE CALIPERS; 		- 1
PE
 Enquire
5 670307750
RH REAR CALIPER ASSEMBLY
Available with: FUORISERIE - WHITE BRAKE CALIPERS Not available with: FUORISERIE - BRAKE CALIPERS PAINTED - GIALLO LIME, FUORISERIE - ORANGE BRAKE CALIPERS; 		- 1
PE
 Enquire
5 670307751
RH REAR CALIPER ASSEMBLY
Available with: FUORISERIE - ORANGE BRAKE CALIPERS Not available with: FUORISERIE - BRAKE CALIPERS PAINTED - GIALLO LIME, FUORISERIE - WHITE BRAKE CALIPERS; 		- 1
PE
 Enquire
5 670294143
BRAKE REAR LH BLACK
Available with: BLACK BRAKE CALIPERS Not available with: BRAKE CALIPERS IN BLUE, BRAKE CALIPERS ANODIZED IN RED, BRAKE CALIPERS IN DARK COPPER, BRAKE CALIPERS ANODIZED IN BLACK, RED BRAKE CALIPERS, BRAKE CALIPERS PAINTED IN YELLOW; 		$711.63 1
TO
5 670294144
brake rear lh red
Available with: RED BRAKE CALIPERS Not available with: BRAKE CALIPERS IN BLUE, BRAKE CALIPERS ANODIZED IN RED, BRAKE CALIPERS IN DARK COPPER, BRAKE CALIPERS ANODIZED IN BLACK, BLACK BRAKE CALIPERS, BRAKE CALIPERS PAINTED IN YELLOW; 		$984.21 1
TO
5 670294147
LH REAR CALIPER ASSEMBLY
Available with: BRAKE CALIPERS ANODIZED IN RED Not available with: BRAKE CALIPERS IN BLUE, BRAKE CALIPERS IN DARK COPPER, BRAKE CALIPERS ANODIZED IN BLACK, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS, BRAKE CALIPERS PAINTED IN YELLOW; 		- 1
PE
 Enquire
5 670294149
brake rear lh blue
Available with: BRAKE CALIPERS IN BLUE Not available with: BRAKE CALIPERS ANODIZED IN RED, BRAKE CALIPERS IN DARK COPPER, BRAKE CALIPERS ANODIZED IN BLACK, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS, BRAKE CALIPERS PAINTED IN YELLOW; 		$970.95 1
TO
5 670294182
BRAKE REAR RH BLACK
Available with: BLACK BRAKE CALIPERS Not available with: BRAKE CALIPERS IN BLUE, BRAKE CALIPERS ANODIZED IN RED, BRAKE CALIPERS IN DARK COPPER, BRAKE CALIPERS ANODIZED IN BLACK, RED BRAKE CALIPERS, BRAKE CALIPERS PAINTED IN YELLOW; 		$711.63 1
TO
5 670294183
brake rear rh red
Available with: RED BRAKE CALIPERS Not available with: BRAKE CALIPERS IN BLUE, BRAKE CALIPERS ANODIZED IN RED, BRAKE CALIPERS IN DARK COPPER, BRAKE CALIPERS ANODIZED IN BLACK, BLACK BRAKE CALIPERS, BRAKE CALIPERS PAINTED IN YELLOW; 		$984.21 1
TO
5 670294186
RH REAR CALIPER ASSEMBLY
Available with: BRAKE CALIPERS ANODIZED IN RED Not available with: BRAKE CALIPERS IN BLUE, BRAKE CALIPERS IN DARK COPPER, BRAKE CALIPERS ANODIZED IN BLACK, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS, BRAKE CALIPERS PAINTED IN YELLOW; 		- 1
PE
 Enquire
5 670294188
brake rear rh blue
Available with: BRAKE CALIPERS IN BLUE Not available with: BRAKE CALIPERS ANODIZED IN RED, BRAKE CALIPERS IN DARK COPPER, BRAKE CALIPERS ANODIZED IN BLACK, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS, BRAKE CALIPERS PAINTED IN YELLOW; 		$970.95 1
TO
6 675001192
SCREW 		$5.46 4
TO
7 670158702
FLEXIBLE HOSE 		$11.29 2
TO
8 670162021
BRAKE CLAMP REAR LH 		$7.11 1
TO
8 670162020
BRAKE CLAMP REAR RH 		$7.11 1
TO
9 675000432
SCREWM6X20 		$2.54 4
TO
12 673014160
REAR BRAKE PADS 		$325.65 1
TO
13 673010932
SPRING AND PINS KIT 		$122.59 2
TO
14 673001646
BLEEDER SCREW AND PLUG 		$33.78 2
TO
15 673010936
LH BRACKET AND SCREW 		$51.13 1
TO
15 673010935
RH BRACKET AND SCREW 		$51.13 1
TO
