Lamborghini Gallardo LP570 4 SL - Water Cooling System 3

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	N10005109	SCREW M8X35	N10005109 SCREW M8X35	$2.72	8
002	400121277	DISTANCE PIECE	400121277 DISTANCE PIECE	$10.13	8
003	400121268	RUBBER BUSH	400121268 RUBBER BUSH	$11.30	8
004	WHT001189	PLASTIC WASHER IN STOCK	WHT001189 PLASTIC WASHER IN STOCK	$6.13	8
005	WHT001942	WASHER IN STOCK	WHT001942 WASHER IN STOCK	$3.22	8
006	N10653201	HEX COLLARED BOLT IN STOCK	N10653201 HEX COLLARED BOLT IN STOCK	$1.92	8
007	400121241	LH BRACKET	400121241 LH BRACKET	$90.97	1
008	400121240	RH BRACKET	400121240 RH BRACKET	$287.01	1
009	400121232	RH BRACKET	400121232 RH BRACKET	$333.87	1
010	400121233	LH BRACKET	400121233 LH BRACKET	$99.46	1
011	400807946	RH Conveyor IN STOCK	400807946 RH Conveyor IN STOCK	$145.14	1
011	400807945	LH CONVEYOR IN STOCK	400807945 LH CONVEYOR IN STOCK	$145.14	1
012	400809963A	LH CONVEYOR	400809963A LH CONVEYOR	$443.97	1
012	400809964A	RH CONVEYOR IN STOCK	400809964A RH CONVEYOR IN STOCK	$370.11	1
013	N90986803	HEXAGON SOCKET HEAD PANEL BOLT 2 X13 IN STOCK	N90986803 HEXAGON SOCKET HEAD PANEL BOLT 2 X13 IN STOCK	$0.99	2
014	N0454281	CLIP IN STOCK	N0454281 CLIP IN STOCK	$0.90 MSRP: ~~7.24~~ (87.6% off)	2
015	N902324	SCREW M6X10	N902324 SCREW M6X10	-	8	Enquire
016	N10347004	SCREW M6X16 IN STOCK	N10347004 SCREW M6X16 IN STOCK	$0.96 MSRP: ~~7.27~~ (86.8% off)	8
017	WHT002225A	HEXAGON SOCKET HEAD BOLT IN STOCK	WHT002225A HEXAGON SOCKET HEAD BOLT IN STOCK	$1.39 MSRP: ~~7.16~~ (80.6% off)	6
018	N10653201	HEX COLLARED BOLT IN STOCK	N10653201 HEX COLLARED BOLT IN STOCK	$1.92	4
019	N90780903	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N90780903 OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	$0.96	4
020	400121235A	RH BRACKET	400121235A RH BRACKET	$199.02	1
020	400121235	LH BRACKET	400121235 LH BRACKET	$221.35	1
021	400121253D	LH WATER RADIATOR	400121253D LH WATER RADIATOR	$1,963.75	1
021	400121252D	RH WATER RADIATOR IN STOCK	400121252D RH WATER RADIATOR IN STOCK	$2,028.35	1
022	4Z7959455M	RADIATOR ELECTRIC FAN IN STOCK	4Z7959455M RADIATOR ELECTRIC FAN IN STOCK	$1,682.36	2
023	400122194C	RH Support	400122194C RH Support	$596.34	1
023	400122193C	LH SUPPORT	400122193C LH SUPPORT	$497.84	1
024	403807158	RH CONVEYOR	403807158 RH CONVEYOR	$471.57	1
024	403807157	LH CONVEYOR IN STOCK	403807157 LH CONVEYOR IN STOCK	$332.68 MSRP: ~~401.00~~ (17% off)	1
025	N0902324	SCREW M6X10 IN STOCK	N0902324 SCREW M6X10 IN STOCK	$1.02 MSRP: ~~7.25~~ (85.9% off)	4
026	400260197C	BRACKET	400260197C BRACKET	$71.99	1
027	N10569501	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	N10569501 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	$2.11	4
028	N10082911	SCREW M6X16 IN STOCK	N10082911 SCREW M6X16 IN STOCK	$0.67	2
029	400807265	GASKET	400807265 GASKET	$10.31	2
030	400121539	GASKET	400121539 GASKET	$52.08	2
031	420121261A	BRACKET	420121261A BRACKET	$3.63	2
032	1J0971830R	BRACKET FOR CONNECTOR HOUSING IN STOCK	1J0971830R BRACKET FOR CONNECTOR HOUSING IN STOCK	$5.07	2
033	N10347004	SCREW M6X16 IN STOCK	N10347004 SCREW M6X16 IN STOCK	$0.96 MSRP: ~~7.27~~ (86.8% off)	2
