Name: Actuator HSR mounting parts control unit
Rating: 4.4 (1 reviews)

View the exploded parts diagram to find the part you are looking for

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

TO ORDER

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	33346895076	Actuator HSR	$2,256.53	To Order

Photo	Part No	Description	Price (each)	Stock
	31 10 6770256	Hexagon screw with flange	$5.32	To Order

Photo	Part No	Description	Price (each)	Stock
	33 32 6760374	Self-locking collar nut	$5.45	To Order

Photo	Part No	Description	Price (each)	Stock
	31106850776	Screw, self tapping	$11.32	To Order

Photo	Part No	Description	Price (each)	Stock
	07 11 9906489	Hexagon screw with flange	$3.57	To Order

Photo	Part No	Description	Price (each)	Stock
	07147128161	Hexagon screw with flange	$1.62	To Order

Photo	Part No	Description	Price (each)	Stock
	41 24 8147832	Hex nut with flange	$1.41	To Order

Photo	Part No	Description	Price (each)	Stock
	37146869771	Hexagon screw, self-tapping	$1.62	To Order

Photo	Part No	Description	Price (each)	Stock
	07129907889	Heli-Coil threaded insert	$28.27	To Order

Photo	Part No	Description	Price (each)	Stock
	33306786621	Heli-Coil threaded insert	$4.45	To Order

Photo	Part No	Description	Price (each)	Stock
	33306780502	Threaded plug	$7.35	To Order

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Key
01	33346895076	Actuator HSR	33346895076 Actuator HSR	$2,256.53	1	TO
02	31 10 6770256	Hexagon screw with flange	31 10 6770256 Hexagon screw with flange M12X1,5X65-10.9	$5.32	2	TO
03	33 32 6760374	Self-locking collar nut	33 32 6760374 Self-locking collar nut M12X1,5-10 ZNS3	$5.45	4	TO
04	31106850776	Screw, self tapping	31106850776 Screw, self tapping M14X1,5X75-10.9	$11.32	8	TO
05	07 11 9906489	Hexagon screw with flange	07 11 9906489 Hexagon screw with flange M12X1,5X67-10.9	$3.57	1	TO
07	07147128161	Hexagon screw with flange	07147128161 Hexagon screw with flange M6	$1.62	2	TO
08	33346870078	Earth strap	33346870078 Earth strap PHEV; from 09.2021	$51.81	1	TO
08	33348846960	Earth strap	33348846960 Earth strap	$45.37	1	TO
09	41 24 8147832	Hex nut with flange	41 24 8147832 Hex nut with flange M6	$1.41	1	TO
10	37146869771	Hexagon screw, self-tapping	37146869771 Hexagon screw, self-tapping M6X16	$1.62	1	TO
11	07129907889	Heli-Coil threaded insert	07129907889 Heli-Coil threaded insert M12X1,5X12 - A2	$28.27	1	TO
12	33306786621	Heli-Coil threaded insert	33306786621 Heli-Coil threaded insert M6X12	$4.45	1	TO
13	33306780502	Threaded plug	33306780502 Threaded plug M14X1,5X35	$7.35	4	TO

Actuator Hsr Mounting Parts Control Unit

Rolls Royce Phantom RR11(2017-2023)
