McLaren Senna - 28 - EMISSIONS SYSTEM - 28.1 - SECONDARY AIR INJECTION SYSTEM

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
00RA134 Nut - M6 - Hex Enquire To Order
Photo Part No Description Price (each) Stock
00RB137 HOSE CLAMP - 28.6 - 706R - OETIKER Enquire To Order
Photo Part No Description Price (each) Stock
00RC013 WASHER - M6X18X1.6 Enquire To Order
Photo Part No Description Price (each) Stock
00RG028 CLIP - SWIVEL TYPE - MALE+FEMALE - 23.5-25 Enquire To Order
Photo Part No Description Price (each) Stock
12F0750CP PUMP - SECONDARY AIR $385.87 To Order
Photo Part No Description Price (each) Stock
15F0023CP HOSE - SECONDARY AIR - LH $234.38 To Order
Photo Part No Description Price (each) Stock
15F0024CP HOSE - SECONDARY AIR - RH $217.96 To Order
Photo Part No Description Price (each) Stock
15FA130CP BRACKET - SECONDARY AIR PUMP - RH $81.23 To Order
Photo Part No Description Price (each) Stock
15FA129CP BRACKET - SECONDARY AIR PUMP - LH $81.23 To Order
Photo Part No Description Price (each) Stock
00RA011 NUT-HEX HEAD-FLANGE-M6-8 Enquire To Order
Photo Part No Description Price (each) Stock
00RG019 SWIVEL - 6.5X10.5 FIRTREE BASE Enquire To Order
Photo Part No Description Price (each) Stock
15FA100CP HOSE - SECONDARY AIR INJECTION - INC SENSOR - RH $362.53 To Order
Photo Part No Description Price (each) Stock
00RB097 P-CLIP - DIA 25 - M6 Enquire To Order
Photo Part No Description Price (each) Stock
00RA313 SCREW - M6X16 - HEX - SILVER Enquire To Order
Photo Part No Description Price (each) Stock
15FA099CP ASSY - SAI LH $348.96 To Order
28 - EMISSIONS SYSTEM - 28.1 - SECONDARY AIR INJECTION SYSTEM of McLaren McLaren Senna Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
010 00RA134
Nut - M6 - Hex 		- 6
PE
 Enquire
011 00RB137
HOSE CLAMP - 28.6 - 706R - OETIKER 		- 2
PE
 Enquire
012 00RC013
WASHER - M6X18X1.6 		- 6
PE
 Enquire
013 00RG028
CLIP - SWIVEL TYPE - MALE+FEMALE - 23.5-25 		- 6
PE
 Enquire
014 12F0750CP
PUMP - SECONDARY AIR 		$385.87 2
TO
015 15F0023CP
HOSE - SECONDARY AIR - LH 		$234.38 1
TO
016 15F0024CP
HOSE - SECONDARY AIR - RH 		$217.96 1
TO
017 15FA130CP
BRACKET - SECONDARY AIR PUMP - RH 		$81.23 1
TO
018 15FA129CP
BRACKET - SECONDARY AIR PUMP - LH 		$81.23 1
TO
020 00RA011
NUT-HEX HEAD-FLANGE-M6-8 		- 3
PE
 Enquire
021 00RG019
SWIVEL - 6.5X10.5 FIRTREE BASE 		- 4
PE
 Enquire
022 15FA100CP
HOSE - SECONDARY AIR INJECTION - INC SENSOR - RH 		$362.53 2
TO
023 00RB097
P-CLIP - DIA 25 - M6 		- 4
PE
 Enquire
024 00RA313
SCREW - M6X16 - HEX - SILVER 		- 2
PE
 Enquire
025 15FA099CP
ASSY - SAI LH 		$348.96 2
TO
