Name: 37 - CHARGER SYSTEM - 37.1 - CHARGER
Rating: 4.7 (1 reviews)

Find Your Part

View the exploded parts diagram to find the part you are looking for

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

TO ORDER

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	00RA152	SCREW CAP - M6X25 - HEX SOCKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	00RA011	NUT-HEX HEAD-FLANGE-M6-8	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	00RG024	CABLE TIE - 90 DEG - EDGE PANEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16JA388CP	ASSY INTEGRATED POWER UNIT	Enquire	To Order
	16JA585CP	ASSY INTEGRATED POWER UNIT - CHINA	Enquire	To Order
	16JA584CP	ASSY INTEGRATED POWER UNIT	$12,475.93	To Order

Photo	Part No	Description	Price (each)	Stock
	16JA387CP	ASSY-HV DC CABLE IPU-EAC	$196.37	To Order

Photo	Part No	Description	Price (each)	Stock
	00RG029	Cable Tie - Male - Dia 10-52	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	00RA621	SCREW - M6X24 - BUTTON	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16JA085CP	HYBRID MANUAL DISCONNECT COVER	$71.07	To Order

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Key	Add to Cart
010	16JA106CP	IPU BRACKET SUPPORT RHD	16JA106CP IPU BRACKET SUPPORT RHD	$52.64	1	TO
010	16JA006CP	IPU BRACKET SUPPORT LHD	16JA006CP IPU BRACKET SUPPORT LHD	-	1	PE	Enquire
011	00RA152	SCREW CAP - M6X25 - HEX SOCKET	00RA152 SCREW CAP - M6X25 - HEX SOCKET	-	3	PE	Enquire
012	00RA011	NUT-HEX HEAD-FLANGE-M6-8	00RA011 NUT-HEX HEAD-FLANGE-M6-8	-	2	PE	Enquire
013	00RG024	CABLE TIE - 90 DEG - EDGE PANEL	00RG024 CABLE TIE - 90 DEG - EDGE PANEL	-	1	PE	Enquire
014	16JA388CP	ASSY INTEGRATED POWER UNIT	16JA388CP ASSY INTEGRATED POWER UNIT	-	1	PE	Enquire
014	16JA585CP	ASSY INTEGRATED POWER UNIT - CHINA	16JA585CP ASSY INTEGRATED POWER UNIT - CHINA	-	1	PE	Enquire
014	16JA584CP	ASSY INTEGRATED POWER UNIT	16JA584CP ASSY INTEGRATED POWER UNIT	$12,475.93	1	TO
015	16JA387CP	ASSY-HV DC CABLE IPU-EAC	16JA387CP ASSY-HV DC CABLE IPU-EAC	$196.37	1	TO
016	00RB074	Swivel Clip - 11-13mm - Female	00RB074 Swivel Clip - 11-13mm - Female	-	1	PE	Enquire
016	00RB141	SWIVEL CLIP - FEMALE CSC9	00RB141 SWIVEL CLIP - FEMALE CSC9	-	1	PE	Enquire
017	00RG029	Cable Tie - Male - Dia 10-52	00RG029 Cable Tie - Male - Dia 10-52	-	2	PE	Enquire
018	00RA621	SCREW - M6X24 - BUTTON	00RA621 SCREW - M6X24 - BUTTON	-	2	PE	Enquire
019	16JA085CP	HYBRID MANUAL DISCONNECT COVER	16JA085CP HYBRID MANUAL DISCONNECT COVER	$71.07	1	TO
