3 - Rear Structures - 3.1 - Rear Frame

McLaren Artura

Find Your Part

McLaren Artura - 3 - REAR STRUCTURES - 3.1 - REAR FRAME

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
00RA559 BOLT - HEX HEAD - M10X1.5X40 Enquire To Order
00RA665 SCREW-HEX HEAD-FLANGE-M10X50-10.9 -72 Enquire To Order
Photo Part No Description Price (each) Stock
00RA666 SCREW-HEX HEAD-FLANGE-M10X75-10.9 -72 Enquire To Order
Photo Part No Description Price (each) Stock
16A0528CP SHIM REAR FRAME TO TUB-UPR - 0.5MM $9.20 To Order
Photo Part No Description Price (each) Stock
16A0531CP SHIM REAR FRAME TO TUB-UPR - 0.5MM $6.13 To Order
Photo Part No Description Price (each) Stock
16AD644CP ASSY-RR FRAME $9,707.24 To Order
16AF797CP ASSY-RR FRAME $9,167.96 To Order
Photo Part No Description Price (each) Stock
00RC065 WASHER - M10X21X2.0 Enquire To Order
Photo Part No Description Price (each) Stock
00RA568 BOLT - M6X20 - HEX Enquire To Order
Photo Part No Description Price (each) Stock
16AA713CP BRACKET MOUNTING RR CLAM RH $158.24 To Order
16AF423CP BRACKET MOUNTING RR CLAM RH $128.96 To Order
Photo Part No Description Price (each) Stock
16AA712CP BRACKET MOUNTING RR CLAM LH $158.24 To Order
16AF422CP BRACKET MOUNTING RR CLAM LH $172.62 To Order
Photo Part No Description Price (each) Stock
00RC043 WASHER - M6XOD25 Enquire To Order
3 - REAR STRUCTURES - 3.1 - REAR FRAME of McLaren McLaren Artura Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
000 16AG233CP
ASSY-CRUSH CAN-RR-RH 		$1,421.74 1
TO
000 16AG232CP
ASSY-CRUSH CAN-RR-LH 		$1,421.74 1
TO
000 16FC419CP
SPACER TOP HAT FRAME 		$50.76 2
TO
000 16FC418CP
SPACER ENGINE LINK 		$50.76 2
TO
000 00RX049
BOLT - M8X60 - HEX 		- 2
PE
 Enquire
000 00RA075
NUT - M8-8 - HEX 		- 3
PE
 Enquire
000 00RA504
NUT-HX-FL-LCK-M8X1.25-STL-85 		- 2
PE
 Enquire
010 00RA559
BOLT - HEX HEAD - M10X1.5X40 		- 8
PE
 Enquire
010 00RA665
SCREW-HEX HEAD-FLANGE-M10X50-10.9 -72 		- 8
PE
 Enquire
011 00RA666
SCREW-HEX HEAD-FLANGE-M10X75-10.9 -72 		- 2
PE
 Enquire
012 16A0528CP
SHIM REAR FRAME TO TUB-UPR - 0.5MM 		$9.20 2
TO
013 16A0531CP
SHIM REAR FRAME TO TUB-UPR - 0.5MM 		$6.13 2
TO
014 16AD644CP
ASSY-RR FRAME 		$9,707.24 1
TO
014 16AF797CP
ASSY-RR FRAME 		$9,167.96 1
TO
015 00RC065
WASHER - M10X21X2.0 		- 10
PE
 Enquire
016 00RA568
BOLT - M6X20 - HEX 		- 12
PE
 Enquire
017 16AA713CP
BRACKET MOUNTING RR CLAM RH 		$158.24 1
TO
017 16AF423CP
BRACKET MOUNTING RR CLAM RH 		$128.96 1
TO
018 16AA712CP
BRACKET MOUNTING RR CLAM LH 		$158.24 1
TO
018 16AF422CP
BRACKET MOUNTING RR CLAM LH 		$172.62 1
TO
019 00RC043
WASHER - M6XOD25 		- 2
PE
 Enquire
020 00RA373
SCREW - HEX HEAD - LOCK - M6X25 - 8.8 		- 2
PE
 Enquire
