McLaren 540C Coupe - 20 - SUSPENSION - WHEELS & TYRES REAR - 20.1 - WHEEL & TYRE ASSEMBLIES REAR

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
13B0924CP WHEEL - STANDARD - 20X10.0 - REAR Enquire To Order
Photo Part No Description Price (each) Stock
13B0566CP Wheel - Standard S Variant - 20x10.0 - Rear Enquire To Order
Photo Part No Description Price (each) Stock
13BA169CP SUPER LIGHTWEIGHT - 20X10.0 - REAR Enquire To Order
13BA063CP Wheel - Super Lightweight - 20x10.0 - Rear Enquire To Order
Photo Part No Description Price (each) Stock
13B0930CP WHEEL - LIGHTWEIGHT - 20X10.0 - REAR Enquire To Order
Photo Part No Description Price (each) Stock
13BA273RP TYRE - PIRELLI - 285-35R20 - TROFEO $992.11 To Order
13B1281CP TYRE - PIRELLI - 285-35R20 - CORSA - REAR $1,374.19 To Order
13B0242CP TYRE - PIRELLI - 285-35R20 - WINTER - REAR $1,232.18 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
13B0998CP WHEEL CENTRE CAP CARBON BACKING CARBON TICK $55.84 To Order
13B0997CP WHEEL CENTRE CAP - RED $55.84 To Order
Photo Part No Description Price (each) Stock
11B0709CP Bolt - Locking Wheel - Set - Black $25.37 To Order
11B0708CP Bolt - Locking Wheel - Set - Silver $19.27 To Order
Photo Part No Description Price (each) Stock
13BA113CP TYRE VALVE - TPMS Enquire To Order
Photo Part No Description Price (each) Stock
13M1180CP TRANSDUCER - TYRE PRESSURE MONITOR - 315MHZ Enquire To Order
13M1179CP TRANSDUCER - TYRE PRESSURE MONITOR - 433MHZ $163.38 To Order
Photo Part No Description Price (each) Stock
11B1001CP Bolt - Locking Wheel - Set - Black $172.62 To Order
11B0620CP Bolt - Locking Wheel - Set - Silver $172.62 To Order
Photo Part No Description Price (each) Stock
11B0641CP Key - Locking Wheel Bolt - Code 7750 $121.84 To Order
11B0640CP Key - Locking Wheel Bolt - Code 7749 $121.84 To Order
11B0635CP Key - Locking Wheel Bolt - Code 7744 $121.84 To Order
...and 7 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
11BA002CP Cap - Tyre Valve - Pack of 20 - Black $7.83 To Order
11BA001CP Cap - Tyre Valve - Pack of 20 - Silver $7.83 To Order
Photo Part No Description Price (each) Stock
13BA428RP WHEEL - ULTRA LIGHTWEIGHT - 20X11.0 REAR Enquire To Order
Photo Part No Description Price (each) Stock
13BA270RP WHEEL - SUPER LIGHTWEIGHT - 20X11.0 REAR Enquire To Order
20 - SUSPENSION - WHEELS & TYRES REAR - 20.1 - WHEEL & TYRE ASSEMBLIES REAR of McLaren McLaren 540C Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
010 13B0924CP
WHEEL - STANDARD - 20X10.0 - REAR 		- 2
PE
 Enquire
011 13B0566CP
Wheel - Standard S Variant - 20x10.0 - Rear
Superseded parts: 13BA062CP; 		- 2
PE
 Enquire
012 13BA169CP
SUPER LIGHTWEIGHT - 20X10.0 - REAR 		- 2
PE
 Enquire
012 13BA063CP
Wheel - Super Lightweight - 20x10.0 - Rear
Superseded parts: 13B0574CP; 		- 2
PE
 Enquire
013 13B0930CP
WHEEL - LIGHTWEIGHT - 20X10.0 - REAR 		- 2
PE
 Enquire
014 13BA273RP
TYRE - PIRELLI - 285-35R20 - TROFEO 		$992.11 2
TO
014 13B1281CP
TYRE - PIRELLI - 285-35R20 - CORSA - REAR
Superseded parts: 13B0568CP; 		$1,374.19 2
TO
014 13B0242CP
TYRE - PIRELLI - 285-35R20 - WINTER - REAR 		$1,232.18 2
TO
014 13B0567CP
TYRE - PIRELLI - 285-35R20 - PZERO - REAR 		$959.77 2
TO
015 13B0998CP
WHEEL CENTRE CAP CARBON BACKING CARBON TICK 		$55.84 2
TO
015 13B0997CP
WHEEL CENTRE CAP - RED 		$55.84 2
TO
016 11B0709CP
Bolt - Locking Wheel - Set - Black 		$25.37 10
TO
016 11B0708CP
Bolt - Locking Wheel - Set - Silver 		$19.27 10
TO
017 13BA113CP
TYRE VALVE - TPMS
Superseded parts: 11B0099CP; 		- 2
PE
 Enquire
018 13M1180CP
TRANSDUCER - TYRE PRESSURE MONITOR - 315MHZ 		- 2
PE
 Enquire
018 13M1179CP
TRANSDUCER - TYRE PRESSURE MONITOR - 433MHZ 		$163.38 2
TO
019 11B1001CP
Bolt - Locking Wheel - Set - Black 		$172.62 1
TO
019 11B0620CP
Bolt - Locking Wheel - Set - Silver 		$172.62 1
TO
020 11B0641CP
Key - Locking Wheel Bolt - Code 7750 		$121.84 1
TO
020 11B0640CP
Key - Locking Wheel Bolt - Code 7749 		$121.84 1
TO
020 11B0635CP
Key - Locking Wheel Bolt - Code 7744 		$121.84 1
TO
020 11B0639CP
Key - Locking Wheel Bolt - Code 7748 		$121.84 1
TO
020 11B0638CP
Key - Locking Wheel Bolt - Code 7747 		$121.84 1
TO
020 11B0637CP
Key - Locking Wheel Bolt - Code 7746 		$111.69 1
TO
020 11B0636CP
Key - Locking Wheel Bolt - Code 7745 		$111.69 1
TO
020 11B0634CP
Key - Locking Wheel Bolt - Code 7743 		$121.84 1
TO
020 11B0633CP
Key - Locking Wheel Bolt - Code 7742 		$121.84 1
TO
020 11B0632CP
Key - Locking Wheel Bolt - Code 7741 		$111.69 1
TO
021 11BA002CP
Cap - Tyre Valve - Pack of 20 - Black 		$7.83 1
TO
021 11BA001CP
Cap - Tyre Valve - Pack of 20 - Silver 		$7.83 1
TO
022 15QA094CP
ACCESSORY - TYRE CRADLE SET 		$783.39 1
TO
023 13BA199CP
WINTER WHEEL & TYRE - COMPLETE SET - P13 433MHZ 		- 1
PE
 Enquire
023 13BA198CP
WINTER WHEEL & TYRE - COMPLETE SET - P13 315MHZ 		- 1
PE
 Enquire
024 13BA428RP
WHEEL - ULTRA LIGHTWEIGHT - 20X11.0 REAR
Superseded parts: 13BA271RP; 		- 1
PE
 Enquire
025 13BA270RP
WHEEL - SUPER LIGHTWEIGHT - 20X11.0 REAR 		- 1
PE
 Enquire
