McLaren 12C Spider - 16 - F1 - POWER UNIT - 16.5 - 01 - POWER UNIT - SECONDARY AIR SYSTEM

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
11F0822CP Bolt - M6x16 - Engine Enquire To Order
Photo Part No Description Price (each) Stock
11F0821CP Sensor - Engine Secondary Air - Pressure inc. Bolt $140.97 To Order
Photo Part No Description Price (each) Stock
11F0971CP SAI PIPE ASSY-NO SENSOR-ENGINE $162.46 To Order
Photo Part No Description Price (each) Stock
11F0979CP Pipe - Secondary Air Injection Valve - Cylinder Head - Engine - LH $152.32 To Order
Photo Part No Description Price (each) Stock
11F0257CP Secondary Air Valve - Engine $162.22 To Order
Photo Part No Description Price (each) Stock
11F1970CP GASKET - SECONDARY AIR - INJECTION PIPE TO ENGINE $15.21 To Order
Photo Part No Description Price (each) Stock
11F0980CP Pipe - Secondary Air Injection Valve - Cylinder Head - Engine - RH $152.32 To Order
16 - F1 - POWER UNIT - 16.5 - 01 - POWER UNIT - SECONDARY AIR SYSTEM of McLaren McLaren 12C Spider Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
035 11F0822CP
Bolt - M6x16 - Engine 		- 1
PE
 Enquire
053 11F0821CP
Sensor - Engine Secondary Air - Pressure inc. Bolt 		$140.97 1
TO
054 11F0971CP
SAI PIPE ASSY-NO SENSOR-ENGINE 		$162.46 1
TO
055 11F0979CP
Pipe - Secondary Air Injection Valve - Cylinder Head - Engine - LH 		$152.32 1
TO
056 11F0257CP
Secondary Air Valve - Engine 		$162.22 1
TO
057 11F1970CP
GASKET - SECONDARY AIR - INJECTION PIPE TO ENGINE 		$15.21 4
TO
058 11F0980CP
Pipe - Secondary Air Injection Valve - Cylinder Head - Engine - RH 		$152.32 1
TO
