McLaren 12C Coupe

Find Your Part

McLaren 12C Coupe - 4 - A4 - PANELS, GLAZING, AND PAINT - 4.4 - 03 - ROOF BODYSIDE PANELS

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
11A8734CP Foam - Support - Front Fender - A-Pillar Casting - Outer $29.63 To Order
00RC064 WASHER - M6X18X1.6 - BLACK Enquire To Order
Photo Part No Description Price (each) Stock
11A5371CP WHEEL ARCH LINER-COVER PANEL-R $261.81 To Order
11A4478CP Cover Panel - Wheel Arch Liner - Carbon - RH $2,678.81 To Order
Photo Part No Description Price (each) Stock
11A7166CP Rocker Outer Panel - RH - MY2015 $3,806.75 To Order
11A0592CP Rocker Outer Panel - RH $2,416.97 To Order
Photo Part No Description Price (each) Stock
11A4653CP PAD WHEEL ARCH COVER SUPPORT $30.20 To Order
Photo Part No Description Price (each) Stock
11A7814CP Pad - Support - Front Fender - A-Pillar Casting $35.23 To Order
11A5955CP Pad - Support - Front Fender – A-Pillar Casting - 12C $16.09 To Order
Photo Part No Description Price (each) Stock
11A9842CP Trim - A Post Aero - RH $241.69 To Order
Photo Part No Description Price (each) Stock
11A0640CP Capping Panel - A-Post - RH $483.38 To Order
Photo Part No Description Price (each) Stock
00RM010 Ratchet Rivet - 12.7-20.6 Enquire To Order
Photo Part No Description Price (each) Stock
11A9891CP Roof Assy Superseded parts: 11A1359CP $3,544.89 To Order
Photo Part No Description Price (each) Stock
11A7480CP Heatshield - Bulkhead - Upper - MY2015 - Coupe $906.35 To Order
11A1074CP Heatshield - Bulkhead - Upper $866.06 To Order
Photo Part No Description Price (each) Stock
11A3790CP BULKHEAD BARRIER CENTRE RH $35.54 To Order
Photo Part No Description Price (each) Stock
11A3789CP BULKHEAD BARRIER CENTRE LH $35.54 To Order
Photo Part No Description Price (each) Stock
11A9841CP Trim - A Post Aero - LH $241.69 To Order
Photo Part No Description Price (each) Stock
11A4728CP A-PILLAR CAPPING NVH BLOCK $35.23 To Order
Photo Part No Description Price (each) Stock
11A0639CP Capping Panel - A-Post - LH $483.38 To Order
Photo Part No Description Price (each) Stock
11A7165CP Rocker Outer Panel - LH - MY2015 $4,008.16 To Order
11A0593CP Rocker Outer Panel - LH $2,416.97 To Order
Photo Part No Description Price (each) Stock
11A4479CP Cover Panel - Wheel Arch Liner - Carbon - LH $2,678.81 To Order
11A5370CP Cover Panel - Wheel Arch Liner - LH $261.81 To Order
Photo Part No Description Price (each) Stock
00RA055 NUT - M6 - LOCKING - HEX Enquire To Order
Photo Part No Description Price (each) Stock
00RA120 SCREW - M6X25 - HEX Enquire To Order
Photo Part No Description Price (each) Stock
00RA263 SCREW - M6X20 - BUTTON Enquire To Order
Photo Part No Description Price (each) Stock
00RA309 NUT - M6-SS - HEX Enquire To Order
Photo Part No Description Price (each) Stock
00RA310 BOLT - M6X16 - BUTTON - BTN HD FL M6X16-SS Enquire To Order
Photo Part No Description Price (each) Stock
00RA390 Screw - Button Head - Tuflok - M6x20 - 10.9 Enquire To Order
Photo Part No Description Price (each) Stock
00RA391 Screw - Hex Head - Tuflok - M6x16 - 8.8 Enquire To Order
Photo Part No Description Price (each) Stock
00RA392 BOLT - HEX HEAD - TUFLOK - M6X20 - 8.8 Enquire To Order
Photo Part No Description Price (each) Stock
00RB103 Trim Panel Clip - Raymond - 017842 Enquire To Order
Photo Part No Description Price (each) Stock
00RC043 WASHER - M6XOD25 Enquire To Order
Photo Part No Description Price (each) Stock
00RC051 WASHER - M6X4.0MM Enquire To Order
Photo Part No Description Price (each) Stock
00RC052 WASHER - M6X6.0MM Enquire To Order
Photo Part No Description Price (each) Stock
00RC053 WASHER - M6X2.0MM Enquire To Order
Photo Part No Description Price (each) Stock
00RC077 WASHER - M6X18X1.6 - STAINLESS STEEL Enquire To Order
Photo Part No Description Price (each) Stock
00RG032 Fir Tree Clip - Anixter - 066 6053 Enquire To Order
Photo Part No Description Price (each) Stock
00RK001 Rivnut - Bollhoff - M4 Enquire To Order
Photo Part No Description Price (each) Stock
11A7618CP Bulkhead Barrier Ears - Upper - RH $71.07 To Order
11A3792CP BULKHEAD BARRIER E24S UPPER-RH $35.54 To Order
Photo Part No Description Price (each) Stock
11A4408CP STUD PLATE-BULKHEA24RH $55.84 To Order
Photo Part No Description Price (each) Stock
11A7725CP Cover Panel - Rocker - Carbon - Branded 650S - RH $5,458.35 To Order
11A6909CP COVER PANEL ROCKER CARBON BRANDED MCLAREN - RH $5,458.35 To Order
11A4480CP Cover Panel - Rocker - Carbon - RH $3,887.32 To Order
Photo Part No Description Price (each) Stock
11A7723CP Cover Panel - Rocker - Carbon - Branded 650S - LH $5,458.35 To Order
11A6911CP COVER PANEL ROCKER CARBON BRANDED MCLAREN - LH $5,458.35 To Order
11A4489CP Cover Panel - Rocker - Carbon - LH $3,887.32 To Order
Photo Part No Description Price (each) Stock
11A4758CP BLACK DECAL BODYSIDE REAR LOWE $16.09 To Order
Photo Part No Description Price (each) Stock
11A4863CP NVH Pad - Tick Panel - Forward $25.15 To Order
Photo Part No Description Price (each) Stock
11A4907CP FWD NVH PAD-UPR TICK CLOSING P $35.23 To Order
Photo Part No Description Price (each) Stock
11A5246CP Sealing Patch - Diameter 30 $17.25 To Order
Photo Part No Description Price (each) Stock
11A5422CP NVH Foam - 45mm $14.07 To Order
Photo Part No Description Price (each) Stock
11A5430CP Felt - 120mm $20.13 To Order
Photo Part No Description Price (each) Stock
11A4959CP Seal - Capping - A-Post - RH $110.76 To Order
Photo Part No Description Price (each) Stock
11A4958CP A POST-CAPPING SEA24LH $110.76 To Order
Photo Part No Description Price (each) Stock
00RA430 SCREW - M4X10 - BUTTON HEAD - 10.9 Enquire To Order
Photo Part No Description Price (each) Stock
00RC039 WASHER - M6 - STAR LOCK Enquire To Order
Photo Part No Description Price (each) Stock
00RC057 Washer - OD11.13xID5.26 Enquire To Order
Photo Part No Description Price (each) Stock
11A7617CP Bulkhead Barrier Ears - Upper - LH $71.07 To Order
11A3791CP BULKHEAD BARRIER E24S UPPER-LH $35.54 To Order
Photo Part No Description Price (each) Stock
11A4305CP STUD PLATE-BULKHEA24LH $55.84 To Order
Photo Part No Description Price (each) Stock
00RA061 Screw - M6x16 - Flange Hex Enquire To Order
Photo Part No Description Price (each) Stock
00RA011 NUT-HEX HEAD-FLANGE-M6-8 Enquire To Order
4 - A4 - PANELS, GLAZING, AND PAINT - 4.4 - 03 - ROOF BODYSIDE PANELS of McLaren McLaren 12C Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
000 11A8734CP
Foam - Support - Front Fender - A-Pillar Casting - Outer 		$29.63 2
TO
000 00RC064
WASHER - M6X18X1.6 - BLACK 		- 8
PE
 Enquire
032 11A5371CP
WHEEL ARCH LINER-COVER PANEL-R 		$261.81 1
TO
032 11A4478CP
Cover Panel - Wheel Arch Liner - Carbon - RH 		$2,678.81 1
TO
033 11A7166CP
Rocker Outer Panel - RH - MY2015 		$3,806.75 1
TO
033 11A0592CP
Rocker Outer Panel - RH 		$2,416.97 1
TO
034 11A4653CP
PAD WHEEL ARCH COVER SUPPORT 		$30.20 2
TO
035 11A7814CP
Pad - Support - Front Fender - A-Pillar Casting
Superseded parts: 11A7476CP; 		$35.23 2
TO
035 11A5955CP
Pad - Support - Front Fender – A-Pillar Casting - 12C 		$16.09 2
TO
036 11A9842CP
Trim - A Post Aero - RH
Superseded parts: 11A8975CP; 		$241.69 1
TO
037 11A0640CP
Capping Panel - A-Post - RH 		$483.38 1
TO
038 00RM010
Ratchet Rivet - 12.7-20.6 		- 24
PE
 Enquire
039 11A9891CP
Roof Assy Superseded parts: 11A1359CP
Roof Assy; Superseded parts: 11A1359CP; 		$3,544.89 1
TO
040 11A7480CP
Heatshield - Bulkhead - Upper - MY2015 - Coupe 		$906.35 1
TO
040 11A1074CP
Heatshield - Bulkhead - Upper 		$866.06 1
TO
041 11A3790CP
BULKHEAD BARRIER CENTRE RH 		$35.54 1
TO
042 11A3789CP
BULKHEAD BARRIER CENTRE LH 		$35.54 1
TO
043 11A9841CP
Trim - A Post Aero - LH
Superseded parts: 11A8974CP; 		$241.69 1
TO
044 11A4728CP
A-PILLAR CAPPING NVH BLOCK 		$35.23 2
TO
045 11A0639CP
Capping Panel - A-Post - LH 		$483.38 1
TO
046 11A7165CP
Rocker Outer Panel - LH - MY2015 		$4,008.16 1
TO
046 11A0593CP
Rocker Outer Panel - LH 		$2,416.97 1
TO
047 11A4479CP
Cover Panel - Wheel Arch Liner - Carbon - LH 		$2,678.81 1
TO
047 11A5370CP
Cover Panel - Wheel Arch Liner - LH 		$261.81 1
TO
086 00RA055
NUT - M6 - LOCKING - HEX 		- 6
PE
 Enquire
087 00RA120
SCREW - M6X25 - HEX 		- 1
PE
 Enquire
088 00RA263
SCREW - M6X20 - BUTTON 		- 2
PE
 Enquire
089 00RA309
NUT - M6-SS - HEX 		- 6
PE
 Enquire
090 00RA310
BOLT - M6X16 - BUTTON - BTN HD FL M6X16-SS 		- 4
PE
 Enquire
091 00RA390
Screw - Button Head - Tuflok - M6x20 - 10.9 		- 4
PE
 Enquire
092 00RA391
Screw - Hex Head - Tuflok - M6x16 - 8.8 		- 12
PE
 Enquire
093 00RA392
BOLT - HEX HEAD - TUFLOK - M6X20 - 8.8 		- 6
PE
 Enquire
094 00RB103
Trim Panel Clip - Raymond - 017842 		- 6
PE
 Enquire
095 00RC043
WASHER - M6XOD25 		- 2
PE
 Enquire
096 00RC051
WASHER - M6X4.0MM 		- 1
PE
 Enquire
097 00RC052
WASHER - M6X6.0MM 		- 1
PE
 Enquire
098 00RC053
WASHER - M6X2.0MM 		- 1
PE
 Enquire
099 00RC077
WASHER - M6X18X1.6 - STAINLESS STEEL 		- 10
PE
 Enquire
100 00RG032
Fir Tree Clip - Anixter - 066 6053 		- 6
PE
 Enquire
101 00RK001
Rivnut - Bollhoff - M4 		- 3
PE
 Enquire
103 11A7618CP
Bulkhead Barrier Ears - Upper - RH 		$71.07 1
TO
103 11A3792CP
BULKHEAD BARRIER E24S UPPER-RH 		$35.54 1
TO
104 11A4408CP
STUD PLATE-BULKHEA24RH 		$55.84 1
TO
105 11A7725CP
Cover Panel - Rocker - Carbon - Branded 650S - RH 		$5,458.35 1
TO
105 11A6909CP
COVER PANEL ROCKER CARBON BRANDED MCLAREN - RH 		$5,458.35 1
TO
105 11A4480CP
Cover Panel - Rocker - Carbon - RH 		$3,887.32 1
TO
106 11A7723CP
Cover Panel - Rocker - Carbon - Branded 650S - LH 		$5,458.35 1
TO
106 11A6911CP
COVER PANEL ROCKER CARBON BRANDED MCLAREN - LH 		$5,458.35 1
TO
106 11A4489CP
Cover Panel - Rocker - Carbon - LH 		$3,887.32 1
TO
107 11A4758CP
BLACK DECAL BODYSIDE REAR LOWE 		$16.09 2
TO
108 11A4863CP
NVH Pad - Tick Panel - Forward 		$25.15 2
TO
111 11A4907CP
FWD NVH PAD-UPR TICK CLOSING P 		$35.23 2
TO
112 11A5246CP
Sealing Patch - Diameter 30 		$17.25 8
TO
113 11A5422CP
NVH Foam - 45mm 		$14.07 4
TO
114 11A5430CP
Felt - 120mm 		$20.13 2
TO
115 11A4959CP
Seal - Capping - A-Post - RH 		$110.76 1
TO
116 11A4958CP
A POST-CAPPING SEA24LH 		$110.76 1
TO
118 00RA430
SCREW - M4X10 - BUTTON HEAD - 10.9 		- 16
PE
 Enquire
120 00RA399
Screw - M4x12 		- 17
PE
 Enquire
123 00RC039
WASHER - M6 - STAR LOCK 		- 11
PE
 Enquire
124 00RC057
Washer - OD11.13xID5.26 		- 8
PE
 Enquire
125 11A7617CP
Bulkhead Barrier Ears - Upper - LH 		$71.07 1
TO
125 11A3791CP
BULKHEAD BARRIER E24S UPPER-LH 		$35.54 1
TO
126 11A4305CP
STUD PLATE-BULKHEA24LH 		$55.84 1
TO
127 00RA061
Screw - M6x16 - Flange Hex 		- 6
PE
 Enquire
128 00RA011
NUT-HEX HEAD-FLANGE-M6-8 		- 4
PE
 Enquire

Haven't found what you're looking for?

Original Parts Tuning Parts Need help? Call us

View Cart / Checkout
