Name: COOLING SYSTEM HIGH VOLTAGE COOLING
Rating: 4.1 (1 reviews)

Diagram
INFO

COOLING SYSTEM HIGH VOLTAGE COOLING of Lamborghini Lamborghini Revuelto Coupe

Lamborghini Revuelto Coupe - COOLING SYSTEM HIGH VOLTAGE COOLING

View the exploded parts diagram to find the part you are looking for

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

TO ORDER

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	47B121251A	COOLER FOR COOLANT	$1,002.22	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0121203C	RADIATOR FAN WITH FAN RING	$940.25	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	47B121473A	BREATHER LINE	$29.74	To Order

Photo	Part No	Description	Price (each)	Stock
	47B121421B	VALVE	$39.80	To Order

Photo	Part No	Description	Price (each)	Stock
	47B122255A	HOSE	$49.45	To Order

Photo	Part No	Description	Price (each)	Stock
	47B121561A	COOLANT PIPE	$66.06	To Order

Photo	Part No	Description	Price (each)	Stock
	47B122253A	HOSE	$50.53	To Order

Photo	Part No	Description	Price (each)	Stock
	47B121391B	SOLENOID VALVE	$313.28	To Order

Photo	Part No	Description	Price (each)	Stock
	4G0121140S	HOSE CONNECTOR	$38.90	To Order

Photo	Part No	Description	Price (each)	Stock
	47B121562A	COOLANT PIPE	$49.93	To Order

Photo	Part No	Description	Price (each)	Stock
	47B121411A	SOLENOID VALVE	$994.35	To Order

Photo	Part No	Description	Price (each)	Stock
	47B121548B	COOLANT HOSE	$48.54	To Order

Photo	Part No	Description	Price (each)	Stock
	47B121179A	SPACER	$13.29	To Order

Photo	Part No	Description	Price (each)	Stock
	47B121437	SEALING RING	$4.21	To Order

Photo	Part No	Description	Price (each)	Stock
	050129669C	GROMMET	$9.13	To Order

Photo	Part No	Description	Price (each)	Stock
	N10196103	OVAL SOCKET HEAD BOLT WITH HEX DRIVE	$1.31	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N90687001	SPRING BAND CLAMP	$7.39	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N90687201	SPRING BAND CLAMP	$2.98	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10714801	OVAL HEXAGON SOCKET HEAD BOLT	$0.83	To Order

Photo	Part No	Description	Price (each)	Stock
	N10786201	HEX SOCKET OVAL HEAD COLLARED	$0.93	To Order

Photo	Part No	Description	Price (each)	Stock
	47B121173A	INSERT NUT	$17.34	To Order

Photo	Part No	Description	Price (each)	Stock
	N10551403	HEXAGON SOCKET FLAT HEAD BOLT	$1.31	To Order

Photo	Part No	Description	Price (each)	Stock
	N90543602	WASHER	$1.51	To Order

Photo	Part No	Description	Price (each)	Stock
	N90986501	SPRING BAND CLAMP	$2.29	To Order

Photo	Part No	Description	Price (each)	Stock
	4D0317867A	RUBBER BUSH	$8.48	IN STOCK

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Key
1	47B121251A	COOLER FOR COOLANT	47B121251A COOLER FOR COOLANT	$1,002.22	1	TO
2	4S0121203C	RADIATOR FAN WITH FAN RING IN STOCK	4S0121203C RADIATOR FAN WITH FAN RING 400W IN STOCK	$940.25	1	IN
3	47B121473A	BREATHER LINE	47B121473A BREATHER LINE	$29.74	1	TO
4	47B121421B	VALVE	47B121421B VALVE	$39.80	1	TO
5	47B122255A	HOSE	47B122255A HOSE	$49.45	1	TO
6	47B121561A	COOLANT PIPE	47B121561A COOLANT PIPE	$66.06	1	TO
7	47B122253A	HOSE	47B122253A HOSE	$50.53	1	TO
8	47B121391B	SOLENOID VALVE	47B121391B SOLENOID VALVE	$313.28	1	TO
9	4G0121140S	HOSE CONNECTOR	4G0121140S HOSE CONNECTOR	$38.90	1	TO
10	47B121562A	COOLANT PIPE	47B121562A COOLANT PIPE	$49.93	1	TO
11	47B121411A	SOLENOID VALVE	47B121411A SOLENOID VALVE	$994.35	1	TO
12	47B121548B	COOLANT HOSE	47B121548B COOLANT HOSE	$48.54	1	TO
14	47B121179A	SPACER	47B121179A SPACER	$13.29	1	TO
15	47B121437	SEALING RING	47B121437 SEALING RING	$4.21	1	TO
16	050129669C	GROMMET	050129669C GROMMET	$9.13	1	TO
17	N10196103	OVAL SOCKET HEAD BOLT WITH HEX DRIVE IN STOCK	N10196103 OVAL SOCKET HEAD BOLT WITH HEX DRIVE M6X18 IN STOCK	$1.31	1	IN
18	N90687001	SPRING BAND CLAMP IN STOCK	N90687001 SPRING BAND CLAMP 27X12 IN STOCK	$7.39	1	IN
19	N90687201	SPRING BAND CLAMP IN STOCK	N90687201 SPRING BAND CLAMP 40X12 IN STOCK	$2.98	1	IN
20	N10714801	OVAL HEXAGON SOCKET HEAD BOLT	N10714801 OVAL HEXAGON SOCKET HEAD BOLT M6X18	$0.83	1	TO
21	N10786201	HEX SOCKET OVAL HEAD COLLARED	N10786201 HEX SOCKET OVAL HEAD COLLARED M6X12	$0.93	1	TO
22	47B121173A	INSERT NUT	47B121173A INSERT NUT	$17.34	1	TO
23	N10551403	HEXAGON SOCKET FLAT HEAD BOLT	N10551403 HEXAGON SOCKET FLAT HEAD BOLT	$1.31	1	TO
24	N90543602	WASHER	N90543602 WASHER	$1.51	1	TO
25	N90986501	SPRING BAND CLAMP	N90986501 SPRING BAND CLAMP 14,5X12	$2.29 MSRP: ~~7.10~~ (67.7% off)	1	TO
26	4D0317867A	RUBBER BUSH IN STOCK	4D0317867A RUBBER BUSH IN STOCK	$8.48	1	IN

Cooling System High Voltage Cooling

Lamborghini Revuelto Coupe

Lamborghini Revuelto Coupe - COOLING SYSTEM HIGH VOLTAGE COOLING
