Lh Tank

Lamborghini Gallardo Superleggera

Find Your Part

Lamborghini Gallardo Superleggera - Lh Tank

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Lh Tank of Lamborghini Lamborghini Gallardo Superleggera Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 400201787A
PIPE 		$49.08 1
TO
002 400201558A
GASKET
IN STOCK 		$14.06 1
IN
003 N10207001
SCREW 		$0.76 2
TO
004 400201255
BRACKET 		$11.96 1
TO
005 400201149B
CONNECTOR 		$112.46 1
TO
006 400201511A
Fuel Filter 		$254.25 1
TO
007 400201349
WASHER 		$11.43 1
TO
008 400201149
CONNECTOR 		$59.27 1
TO
009 400201215A
LH PIPE 		$103.53 1
TO
012 400201075A
LH TANK 		$2,594.24 1
TO
014 400201903
PIPE 		$228.55 1
TO
015 1J0919133
GASKET
IN STOCK 		$20.76 1
IN
016 8L0919051H
Pump 		$924.75 1
TO
017 400201099
FLANGE 		$291.60 1
TO
018 400201219A
LH PIPE 		$171.41 1
TO
019 WHT001187
WASHER
IN STOCK 		$0.80 (89% off) 6
IN
020 WHT001194
SCREW
IN STOCK 		$0.36 (95.1% off) 6
IN
021 400201539A
SLEEVE 		$44.08 2
TO
022 400201211
EARTHING STRAP 		$0.96 (86.7% off) 1
TO
