Electrical System (Valid For June 1992 Version) 1

Lamborghini Diablo (1990-1998)

Find Your Part

Lamborghini Diablo (1990-1998) - Electrical System (Valid for June 1992 Version) 1

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Electrical System (Valid for June 1992 Version) 1 of Lamborghini Lamborghini Diablo (1990-1998) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 006130410
ELECT CABLE
(Valid for June 1992 version) CABLAGGIO PARAURTI ANTERIORE 		$482.37 1
TO
002 006133099
ELECT CABLE
(Valid for June 1992 version) CABLAGGIO CENTRALE (dalla 12596 alla 12781) 		- 1
PE
 Enquire
002 006129920
ELECT CABLE
(Valid for June 1992 version) CABLAGGIO CENTRALE (fino alia 12595) 		- 1
PE
 Enquire
002 006133332
ELECT CABLE
(Valid for June 1992 version) CABLAGGIO CENTRALE (dalla 12782) 		$3,188.87 1
TO
003 006130087
ELECT CABLE
(Valid for June 1992 version) CABLAGGIO CENTRALINE CATALYST (fino alla 12540) 		- 1
PE
 Enquire
003 006132503
ELECT CABLE
(Valid for June 1992 version) CABLAGGIO CENTRALINE CATALYST (dalla 12541) 		$631.71 1
TO
004 006131376
ELECT CABLE
(Valid for June 1992 version) CABLAGGIO CENTRALINE ACC./INIEZ. 		$755.39 1
TO
005 006131375
ELECT CABLE
(Valid for June 1992 version) CABLAGGIO MOTORE (fino alia 12348) 		- 1
PE
 Enquire
005 006132502
ELECT CABLE
(Valid for June 1992 version) CABLAGGIO MOTORE (dalla 12349) 		$5,316.79 1
TO
006 006131363
OXIGEN SENS. HARN.
(Valid for June 1992 version) CABLAGGIO SONDE LAMBDA 		$165.51 1
TO
007 006131590
ELECT CABLE
(Valid for June 1992 version) CABLAGGIO PARAURTI POSTERIORE 		$453.48 1
TO
