Name: TRIM FRAME REAR PART
Rating: 4.8 (1 reviews)

Diagram
INFO

TRIM FRAME REAR PART of Lamborghini Lamborghini Aventador LP780 Ultimae

Lamborghini Aventador LP780 Ultimae - TRIM FRAME REAR PART

View the exploded parts diagram to find the part you are looking for

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

TO ORDER

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	470814907C	ARM	$826.22	To Order

Photo	Part No	Description	Price (each)	Stock
	470814908E	ARM	$577.96	To Order

Photo	Part No	Description	Price (each)	Stock
	470814149F	ARM	$209.53	To Order
	470814150C	ARM	$206.22	To Order

Photo	Part No	Description	Price (each)	Stock
	470813541B	BRACKET	$1,523.70	To Order
	470813542B	BRACKET	$2,541.71	To Order

Photo	Part No	Description	Price (each)	Stock
	470813649K	SIDE MEMBER	$625.23	To Order
	470813650E	SIDE MEMBER	$595.05	To Order

Photo	Part No	Description	Price (each)	Stock
	N91000203	OVAL HEXAGON SOCKET HEAD BOLT	$11.30	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N90786503	HEXAGON HEAD BOLT (COMBI)	$2.29	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N90862302	HEXAGON HEAD BOLT (COMBI)	$6.05	To Order

Photo	Part No	Description	Price (each)	Stock
	8H0806221	COMPENSATING PIECE	$10.90	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	470807307E	BUMPER CARRIER	$10,889.20	To Order

Photo	Part No	Description	Price (each)	Stock
	N90900402	HEX SOCKET OVAL HEAD COLLARED	$1.21	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4D0317867A	RUBBER BUSH	$8.48	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	470814908E	ARM	$577.96	To Order

Photo	Part No	Description	Price (each)	Stock
	470813983A	ARM	$1,133.57	To Order

Photo	Part No	Description	Price (each)	Stock
	470813381	ARM	$1,040.34	To Order

Photo	Part No	Description	Price (each)	Stock
	470814942C	BRACKET	$82.88	To Order

Diagram Tap to enlarge

	#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Key
	1	470814907C	ARM	470814907C ARM LEFT REAR	$826.22	1	TO
	470814908E		ARM	from $577.96
2 ARM $577.96 1 TO 17 ARM $577.96 1 TO
	3	470814149F	ARM	470814149F ARM LEFT REAR	$209.53	1	TO
	3	470814150C	ARM	470814150C ARM CONTACT YOUR AREA MANAGER-RIGHT REAR	$206.22	1	TO
	4	470813541B	BRACKET	470813541B BRACKET CONTACT YOUR AREA MANAGER-LEFT	$1,523.70	1	TO
	4	470813542B	BRACKET	470813542B BRACKET CONTACT YOUR AREA MANAGER-RIGHT	$2,541.71	1	TO
	5	470813649K	SIDE MEMBER	470813649K SIDE MEMBER CONTACT YOUR AREA MANAGER-LEFT REAR	$625.23	1	TO
	5	470813650E	SIDE MEMBER	470813650E SIDE MEMBER CONTACT YOUR AREA MANAGER-RIGHT REAR	$595.05	1	TO
	8	N91000203	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N91000203 OVAL HEXAGON SOCKET HEAD BOLT M8X25-H IN STOCK	$11.30	32	IN
	9	N90786503	HEXAGON HEAD BOLT (COMBI) IN STOCK	N90786503 HEXAGON HEAD BOLT (COMBI) M8X20 IN STOCK	$2.29 MSRP: ~~7.16~~ (68% off)	2	IN
	10	N90862302	HEXAGON HEAD BOLT (COMBI)	N90862302 HEXAGON HEAD BOLT (COMBI) M8X40	$6.05	2	TO
	11	8H0806221	COMPENSATING PIECE IN STOCK	8H0806221 COMPENSATING PIECE IN STOCK	$10.90	2	IN
	14	470807307E	BUMPER CARRIER	470807307E BUMPER CARRIER CONTACT YOUR AREA MANAGER-REAR	$10,889.20	1	TO
	15	N90900402	HEX SOCKET OVAL HEAD COLLARED IN STOCK	N90900402 HEX SOCKET OVAL HEAD COLLARED M6X20 IN STOCK	$1.21 MSRP: ~~7.24~~ (83.3% off)	4	IN
	16	4D0317867A	RUBBER BUSH IN STOCK	4D0317867A RUBBER BUSH IN STOCK	$8.48	2	IN
	18	470813983A	ARM	470813983A ARM RIGHT REAR	$1,133.57	1	TO
	19	470813381	ARM	470813381 ARM CONTACT YOUR AREA MANAGER-RIGHT REAR	$1,040.34	1	TO
	20	470814942C	BRACKET	470814942C BRACKET CONTACT YOUR AREA MANAGER-REAR	$82.88	1	TO

Trim Frame Rear Part

Lamborghini Aventador LP780 Ultimae

Lamborghini Aventador LP780 Ultimae - TRIM FRAME REAR PART
