Name: A/C CONDENSER
Rating: 4.4 (1 reviews)

Diagram
INFO

A/C CONDENSER of Lamborghini Lamborghini Aventador LP780 Ultimae

Lamborghini Aventador LP780 Ultimae - A/C CONDENSER

View the exploded parts diagram to find the part you are looking for

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

TO ORDER

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	470260401A	AIR CONDITIONING CONDENSER	$990.43	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N90942301	CLAMP	$9.99	To Order

Photo	Part No	Description	Price (each)	Stock
	N10347204	HEXAGON SOCKET HEAD BOLT, SELF-LOCKING	$2.24	To Order

Photo	Part No	Description	Price (each)	Stock
	N01508213	HEXAGON COLLAR NUT	$0.20	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10569501	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD	$2.11	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10451408	OVAL HEXAGON SOCKET HEAD BOLT	$1.44	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N91096701	OVAL HEXAGON SOCKET HEAD BOLT	$1.60	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4E0260749B	SEAL RING	$6.30	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	7H0820896	O-RING	$5.53	To Order

Photo	Part No	Description	Price (each)	Stock
	470260702D	FLANGED PIPE	$313.95	To Order

Photo	Part No	Description	Price (each)	Stock
	470260701B	FLANGED PIPE	$384.87	To Order

Photo	Part No	Description	Price (each)	Stock
	4E0260749A	SEAL RING	$6.52	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	8E0260749C	SEAL RING	$5.53	To Order

Photo	Part No	Description	Price (each)	Stock
	470260709C	FLANGED PIPE	$1,766.70	To Order

Photo	Part No	Description	Price (each)	Stock
	470201809	BRACKET	$32.83	To Order

Photo	Part No	Description	Price (each)	Stock
	4H0959126C	PRESSURE SENDER FOR REFRIGERANT CIRCUIT	$48.51	To Order

Photo	Part No	Description	Price (each)	Stock
	N0206405	CLAMP	$1.97	To Order

Photo	Part No	Description	Price (each)	Stock
	N10414402	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	$3.03	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	470260427A	BRACKET	$38.96	To Order

Photo	Part No	Description	Price (each)	Stock
	470260428A	BRACKET	$38.90	To Order

Photo	Part No	Description	Price (each)	Stock
	470260761	BRACKET	$37.30	To Order

Photo	Part No	Description	Price (each)	Stock
	N91032702	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD	$1.60	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	3W0971838	CABLE TIES	$1.19	To Order

Photo	Part No	Description	Price (each)	Stock
	N10562301	CABLE TIES	$1.29	To Order

Photo	Part No	Description	Price (each)	Stock
	470260423	SPONGE	$49.79	To Order

Photo	Part No	Description	Price (each)	Stock
	3D0971838M	CABLE TIE WITH TERMINAL SOCKET	$2.98	IN STOCK

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Key
1	470260401A	AIR CONDITIONING CONDENSER IN STOCK	470260401A AIR CONDITIONING CONDENSER IN STOCK	$990.43	1	IN
2	N90942301	CLAMP	N90942301 CLAMP 48X15	$9.99	1	TO
3	N10347204	HEXAGON SOCKET HEAD BOLT, SELF-LOCKING	N10347204 HEXAGON SOCKET HEAD BOLT, SELF-LOCKING M6X25	$2.24 MSRP: ~~7.26~~ (69.1% off)	3	TO
4	N01508213	HEXAGON COLLAR NUT IN STOCK	N01508213 HEXAGON COLLAR NUT M6 IN STOCK	$0.20	1	IN
5	N10569501	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	N10569501 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD M5X16 IN STOCK	$2.11	4	IN
6	N10451408	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N10451408 OVAL HEXAGON SOCKET HEAD BOLT M6X16 IN STOCK	$1.44	4	IN
7	N91096701	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N91096701 OVAL HEXAGON SOCKET HEAD BOLT M6X16 IN STOCK	$1.60	2	IN
8	4E0260749B	SEAL RING IN STOCK	4E0260749B SEAL RING 13 -7X2,5 IN STOCK	$6.30 MSRP: ~~7.06~~ (10.8% off)	2	IN
9	7H0820896	O-RING	7H0820896 O-RING 7 -6X1,8	$5.53 MSRP: ~~7.21~~ (23.3% off)	1	TO
10	470260702D	FLANGED PIPE	470260702D FLANGED PIPE	$313.95	1	TO
11	470260701B	FLANGED PIPE	470260701B FLANGED PIPE	$384.87	1	TO
12	4E0260749A	SEAL RING IN STOCK	4E0260749A SEAL RING 11X2 -5 IN STOCK	$6.52 MSRP: ~~7.06~~ (7.6% off)	2	IN
13	8E0260749C	SEAL RING	8E0260749C SEAL RING 23 -8X2,4	$5.53 MSRP: ~~7.09~~ (22% off)	1	TO
14	470260709C	FLANGED PIPE	470260709C FLANGED PIPE	$1,766.70	1	TO
15	470201809	BRACKET	470201809 BRACKET	$32.83	1	TO
16	4H0959126C	PRESSURE SENDER FOR REFRIGERANT CIRCUIT	4H0959126C PRESSURE SENDER FOR REFRIGERANT CIRCUIT	$48.51	1	TO
17	N0206405	CLAMP	N0206405 CLAMP 18X15	$1.97 MSRP: ~~7.07~~ (72.1% off)	1	TO
18	N10414402	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD IN STOCK	N10414402 SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD M8X28 IN STOCK	$3.03 MSRP: ~~7.07~~ (57.1% off)	2	IN
21	470260427A	BRACKET	470260427A BRACKET LEFT	$38.96	1	TO
22	470260428A	BRACKET	470260428A BRACKET RIGHT	$38.90	1	TO
26	470260761	BRACKET	470260761 BRACKET	$37.30	1	TO
27	N91032702	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	N91032702 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD M6X20 IN STOCK	$1.60	4	IN
28	3W0971838	CABLE TIES	3W0971838 CABLE TIES 4 -6X193MM 6,5/0,3-3,0MM	$1.19 MSRP: ~~7.23~~ (83.5% off)	1	TO
29	N10562301	CABLE TIES	N10562301 CABLE TIES 4 -7X194	$1.29 MSRP: ~~7.18~~ (82% off)	2	TO
30	470260423	SPONGE	470260423 SPONGE	$49.79	2	TO
31	3D0971838M	CABLE TIE WITH TERMINAL SOCKET IN STOCK	3D0971838M CABLE TIE WITH TERMINAL SOCKET 4 -6X200MM 1-3MM IN STOCK	$2.98	1	IN

A/C Condenser

Lamborghini Aventador LP780 Ultimae

Lamborghini Aventador LP780 Ultimae - A/C CONDENSER
