Timing System Drive

Ferrari 12Cilindri

Find Your Part

Ferrari 12Cilindri - TIMING SYSTEM DRIVE

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
920858 VALVE TIMING AND PUMP DRIVE SYSTEM $1,488.22 To Order
55038018 VALVE TIMING AND PUMP DRIVE SYSTEM $1,460.96 To Order
Photo Part No Description Price (each) Stock
312629 CHAIN $461.31 To Order
Photo Part No Description Price (each) Stock
271880 CHAIN $133.77 To Order
Photo Part No Description Price (each) Stock
254263 CHAIN $112.83 To Order
Photo Part No Description Price (each) Stock
239566 COMPL. UPPER FIXED SHOE $45.43 To Order
Photo Part No Description Price (each) Stock
16043124 SCREW $0.17 IN STOCK
Photo Part No Description Price (each) Stock
194262 SHOULDER $39.97 To Order
Photo Part No Description Price (each) Stock
187742 ROLLER BEARING CAGE $11.40 To Order
Photo Part No Description Price (each) Stock
154191 GASKET $1.34 IN STOCK
Photo Part No Description Price (each) Stock
181336 SCREW $3.23 IN STOCK
Photo Part No Description Price (each) Stock
289896 MOUNTING $194.78 To Order
Photo Part No Description Price (each) Stock
904999 MOBILE SHOE $389.58 To Order
Photo Part No Description Price (each) Stock
828954 FIXED SHOE $233.74 To Order
Photo Part No Description Price (each) Stock
12649624 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
186668 SCREW $14.83 To Order
Photo Part No Description Price (each) Stock
309750 FIXED SHOE $71.40 To Order
Photo Part No Description Price (each) Stock
282395 SCREW $0.61 To Order
Photo Part No Description Price (each) Stock
198034 FIXED SHOE $70.72 To Order
Photo Part No Description Price (each) Stock
163759 WASHER $13.68 To Order
Photo Part No Description Price (each) Stock
14306224 SCREW $0.20 To Order
Photo Part No Description Price (each) Stock
265180 MOUNTING $70.11 To Order
Photo Part No Description Price (each) Stock
257626 SHOE $90.88 To Order
Photo Part No Description Price (each) Stock
282393 SCREW $0.70 To Order
Photo Part No Description Price (each) Stock
260614 MOBILE SHOE $415.55 To Order
Photo Part No Description Price (each) Stock
16100824 NUT $0.14 To Order
Photo Part No Description Price (each) Stock
175303 BUSH $33.75 To Order
Photo Part No Description Price (each) Stock
175306 SHOULDER $4.12 To Order
Photo Part No Description Price (each) Stock
317023 GASKET $9.60 To Order
Photo Part No Description Price (each) Stock
268314 BUSH $47.22 To Order
Photo Part No Description Price (each) Stock
840915 HYDRAULIC CHAIN TENSIONER $259.71 To Order
55038019 HYDRAULIC CHAIN TENSIONER $246.72 To Order
Photo Part No Description Price (each) Stock
183929 BUSH $6.83 To Order
Photo Part No Description Price (each) Stock
317022 GASKET $3.23 To Order
Photo Part No Description Price (each) Stock
252512 BUSH $92.19 To Order
Photo Part No Description Price (each) Stock
231619 SCREW $0.30 IN STOCK
Photo Part No Description Price (each) Stock
299589 DRIVE GEAR $441.52 To Order
Photo Part No Description Price (each) Stock
828978 PUMP DRIVE GEAR Enquire To Order
Photo Part No Description Price (each) Stock
301217 EXTERNAL CRANKSHAFT GEAR $194.78 To Order
Photo Part No Description Price (each) Stock
299590 INNER CRANKSHAFT GEAR $272.69 To Order
TIMING SYSTEM DRIVE of Ferrari Ferrari 12Cilindri Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 920858
VALVE TIMING AND PUMP DRIVE SYSTEM
Applicable up to engine No. 576797; Not applicable for: NIRL 		$1,488.22 1
TO
1 55038018
VALVE TIMING AND PUMP DRIVE SYSTEM
Applicable from engine No. 576798 		$1,460.96 1
TO
2 312629
CHAIN 		$461.31 1
TO
3 271880
CHAIN 		$133.77 1
TO
4 254263
CHAIN 		$112.83 2
TO
5 239566
COMPL. UPPER FIXED SHOE 		$45.43 2
TO
6 16043124
SCREW
M8 X 14
IN STOCK 		$0.17 1
IN
7 194262
SHOULDER 		$39.97 1
TO
8 187742
ROLLER BEARING CAGE 		$11.40 3
TO
9 154191
GASKET
Also included in engine gasket set
IN STOCK 		$1.34 (46.8% off) 1
IN
10 181336
SCREW
M6 X 16
IN STOCK 		$3.23 (32% off) 9
IN
11 289896
MOUNTING 		$194.78 1
TO
12 904999
MOBILE SHOE 		$389.58 1
TO
13 828954
FIXED SHOE 		$233.74 1
TO
14 12649624
WASHER 		- 2
PE
 Enquire
15 186668
SCREW
M5 X 12 		$14.83 4
TO
16 309750
FIXED SHOE 		$71.40 1
TO
17 282395
SCREW
M6 X 20 		$0.61 2
TO
18 198034
FIXED SHOE 		$70.72 2
TO
19 163759
WASHER 		$13.68 3
TO
20 14306224
SCREW
M8 X 16 		$0.20 (50% off) 3
TO
21 265180
MOUNTING 		$70.11 1
TO
22 257626
SHOE 		$90.88 1
TO
23 282393
SCREW
M6 X 14 		$0.70 2
TO
24 260614
MOBILE SHOE 		$415.55 2
TO
25 16100824
NUT 		$0.14 (26.3% off) 2
TO
26 175303
BUSH 		$33.75 2
TO
27 175306
SHOULDER 		$4.12 1
TO
28 317023
GASKET 		$9.60 1
TO
29 268314
BUSH 		$47.22 1
TO
30 840915
HYDRAULIC CHAIN TENSIONER
Applicable up to engine No. 576797; Not applicable for: NIRL 		$259.71 2
TO
30 55038019
HYDRAULIC CHAIN TENSIONER
For vehicles up to engine No. 576797, replace as a pair; Applicable from engine No. 576798 		$246.72 2
TO
31 183929
BUSH 		$6.83 1
TO
32 317022
GASKET
Also included in engine gasket set 		$3.23 1
TO
33 252512
BUSH 		$92.19 1
TO
34 231619
SCREW
M6 X 18
IN STOCK 		$0.30 4
IN
35 299589
DRIVE GEAR 		$441.52 1
TO
36 828978
PUMP DRIVE GEAR 		- 1
PE
 Enquire
37 301217
EXTERNAL CRANKSHAFT GEAR
Z. 26- -External 		$194.78 1
TO
38 299590
INNER CRANKSHAFT GEAR
Z. 26- -Internal 		$272.69 1
TO
