Cylinder Heads - Timing

Ferrari 12Cilindri

Find Your Part

Ferrari 12Cilindri - CYLINDER HEADS - TIMING

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
831968 RH INTAKE CAMSHAFT $833.56 To Order
Photo Part No Description Price (each) Stock
831969 LH INTAKE CAMSHAFT $833.56 To Order
Photo Part No Description Price (each) Stock
831970 RH EXHAUST CAMSHAFT $805.78 To Order
Photo Part No Description Price (each) Stock
831971 LH EXHAUST CAMSHAFT $805.78 To Order
Photo Part No Description Price (each) Stock
248020 VARIABLE VALVE TIMING ADJUSTER, EXHAUST CAMSHAFT $496.50 IN STOCK
Photo Part No Description Price (each) Stock
241906 VARIABLE VALVE TIMING ADJUSTER, INTAKE CAMSHAFT $496.50 IN STOCK
Photo Part No Description Price (each) Stock
254892 SCREW $12.52 IN STOCK
Photo Part No Description Price (each) Stock
240559 DIAMOND COATED WASHER $8.40 IN STOCK
Photo Part No Description Price (each) Stock
197975 SEAL RING $7.07 IN STOCK
Photo Part No Description Price (each) Stock
777849 INTAKE VALVE $66.22 To Order
911024 EXHAUST VALVE $150.68 To Order
Photo Part No Description Price (each) Stock
911028 LOWER VALVE SPRING CAP $10.25 To Order
Photo Part No Description Price (each) Stock
910743 INTERNAL VALVE RETURN SPRING $25.96 To Order
Photo Part No Description Price (each) Stock
899547 OIL SEAL FOR VALVE SEAL $4.80 To Order
Photo Part No Description Price (each) Stock
776263 UPPER VALVE SPRING CAP $20.77 To Order
Photo Part No Description Price (each) Stock
179763 VALVE SPRING SEMI-CONE $0.87 To Order
Photo Part No Description Price (each) Stock
910742 EXTERNAL VALVE RETURN SPRING $25.96 To Order
Photo Part No Description Price (each) Stock
973895 CAM PAD ROLLER FINGER Enquire To Order
Photo Part No Description Price (each) Stock
830096 TAPPET FOR ROLLER FINGER $41.53 To Order
CYLINDER HEADS - TIMING of Ferrari Ferrari 12Cilindri Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 831968
RH INTAKE CAMSHAFT 		$833.56 1
TO
2 831969
LH INTAKE CAMSHAFT 		$833.56 1
TO
3 831970
RH EXHAUST CAMSHAFT 		$805.78 1
TO
4 831971
LH EXHAUST CAMSHAFT 		$805.78 1
TO
5 248020
VARIABLE VALVE TIMING ADJUSTER, EXHAUST CAMSHAFT
IN STOCK 		$496.50 2
IN
6 241906
VARIABLE VALVE TIMING ADJUSTER, INTAKE CAMSHAFT
IN STOCK 		$496.50 2
IN
7 254892
SCREW
M14 X 1.5
IN STOCK 		$12.52 4
IN
8 240559
DIAMOND COATED WASHER
IN STOCK 		$8.40 4
IN
9 197975
SEAL RING
IN STOCK 		$7.07 (45% off) 12
IN
10 777849
INTAKE VALVE 		$66.22 24
TO
10 911024
EXHAUST VALVE 		$150.68 24
TO
11 911028
LOWER VALVE SPRING CAP 		$10.25 48
TO
12 910743
INTERNAL VALVE RETURN SPRING 		$25.96 48
TO
13 899547
OIL SEAL FOR VALVE SEAL 		$4.80 48
TO
14 776263
UPPER VALVE SPRING CAP 		$20.77 48
TO
15 179763
VALVE SPRING SEMI-CONE 		$0.87 (3.3% off) 96
TO
16 910742
EXTERNAL VALVE RETURN SPRING 		$25.96 48
TO
17 973895
CAM PAD ROLLER FINGER 		- 48
PE
 Enquire
18 830096
TAPPET FOR ROLLER FINGER 		$41.53 48
TO
