44 - Hybrid - 44.3 - Emotors

McLaren P1 Coupe

Find Your Part

McLaren P1 Coupe - 44 - HYBRID - 44.3 - EMOTORS

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
TO ORDER
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
00RB019 CLIP - 90DEG - FEMALE - 10-12MM Enquire To Order
00RB046 CLIP - 8-9MM - FEMALE Enquire To Order
00RB034 CLIP - 14-15MM - MALE Enquire To Order
...and 2 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
12J0315CP Kit - E-Motor Bolts $452.06 To Order
12J0254CP E-Motor $154,483.11 To Order
Photo Part No Description Price (each) Stock
00RA481 BOLT - HEX HEAD - FLANGED - M8X45 Enquire To Order
Photo Part No Description Price (each) Stock
12J0224CP BRACKET - E MOTOR $2,559.16 To Order
Photo Part No Description Price (each) Stock
00RA457 SCREW - M10X30-10.9 - HEX Enquire To Order
Photo Part No Description Price (each) Stock
12J0231CP Wiring Harness - Resolver - E-Motor $1,510.61 To Order
Photo Part No Description Price (each) Stock
00RB003 P Clip - DIA 14 Enquire To Order
Photo Part No Description Price (each) Stock
00RA061 Screw - M6x16 - Flange Hex Enquire To Order
Photo Part No Description Price (each) Stock
00RB039 Swivel Clip - Double - 9.2-10.4 Enquire To Order
Photo Part No Description Price (each) Stock
00RB078 SWIVEL CLIP - 8-9MM - MALE Enquire To Order
Photo Part No Description Price (each) Stock
00RB141 SWIVEL CLIP - FEMALE CSC9 Enquire To Order
Photo Part No Description Price (each) Stock
00RL023 CABLE TIE - HIGH TEMP Enquire To Order
Photo Part No Description Price (each) Stock
12J0307CP Wear Plate - Phase Cable $40.60 To Order
Photo Part No Description Price (each) Stock
12J0196CP Cable Restraint - 3-Way $223.40 To Order
Photo Part No Description Price (each) Stock
00RA098 Screw - M5x16 - Button Enquire To Order
Photo Part No Description Price (each) Stock
12J0308CP Tray - Upper - Phase Cable $142.16 To Order
Photo Part No Description Price (each) Stock
12J0309CP Tray - Lower - Phase Cable $121.84 To Order
Photo Part No Description Price (each) Stock
00RA002 BOLT - M8X20 - HEX Enquire To Order
Photo Part No Description Price (each) Stock
00RA062 SCREW-HEX HEAD-FLA24E-M8X16-8. Enquire To Order
Photo Part No Description Price (each) Stock
00RA064 BOLT - M5X12 - HEX Enquire To Order
Photo Part No Description Price (each) Stock
00RA428 LOCKING NUT M5 - HEX Enquire To Order
Photo Part No Description Price (each) Stock
00RA083 SCREW - M6X20 - FLANGE HEX Enquire To Order
44 - HYBRID - 44.3 - EMOTORS of McLaren McLaren P1 Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
000 00RB019
CLIP - 90DEG - FEMALE - 10-12MM 		- 1
PE
 Enquire
000 00RB046
CLIP - 8-9MM - FEMALE 		- 2
PE
 Enquire
000 00RB034
CLIP - 14-15MM - MALE 		- 1
PE
 Enquire
000 00RB045
CLIP - 9.5-10MM - MALE 		- 1
PE
 Enquire
000 12JA182CP
Tape - Phase Cable - Anti-Friction - 5102 		$111.69 1
TO
010 12J0315CP
Kit - E-Motor Bolts 		$452.06 1
TO
010 12J0254CP
E-Motor
E-Motor; 		$154,483.11 1
TO
012 00RA481
BOLT - HEX HEAD - FLANGED - M8X45 		- 4
PE
 Enquire
013 12J0224CP
BRACKET - E MOTOR 		$2,559.16 1
TO
014 00RA457
SCREW - M10X30-10.9 - HEX 		- 4
PE
 Enquire
015 12J0231CP
Wiring Harness - Resolver - E-Motor 		$1,510.61 1
TO
016 00RB003
P Clip - DIA 14 		- 3
PE
 Enquire
017 00RA061
Screw - M6x16 - Flange Hex 		- 2
PE
 Enquire
020 00RL022
EDGE CLIP - 202X4.6MM - INLINE 		- 2
PE
 Enquire
021 00RB039
Swivel Clip - Double - 9.2-10.4 		- 1
PE
 Enquire
022 00RB078
SWIVEL CLIP - 8-9MM - MALE 		- 1
PE
 Enquire
023 00RB141
SWIVEL CLIP - FEMALE CSC9 		- 1
PE
 Enquire
024 00RL023
CABLE TIE - HIGH TEMP 		- 7
PE
 Enquire
025 12J0307CP
Wear Plate - Phase Cable 		$40.60 1
TO
026 12J0196CP
Cable Restraint - 3-Way 		$223.40 1
TO
027 00RA098
Screw - M5x16 - Button 		- 2
PE
 Enquire
028 12J0308CP
Tray - Upper - Phase Cable 		$142.16 1
TO
029 12J0309CP
Tray - Lower - Phase Cable 		$121.84 1
TO
030 00RA002
BOLT - M8X20 - HEX 		- 3
PE
 Enquire
031 00RA062
SCREW-HEX HEAD-FLA24E-M8X16-8. 		- 1
PE
 Enquire
032 00RA064
BOLT - M5X12 - HEX 		- 4
PE
 Enquire
033 00RA428
LOCKING NUT M5 - HEX 		- 4
PE
 Enquire
034 00RA083
SCREW - M6X20 - FLANGE HEX 		- 1
PE
 Enquire
